GPS Speaker Microphone for TK 2317/TK 3317 Walkie Talkie

Product Overview

Description



GPS Speaker Microphone for Walkie Talkie -GPSMic for Kenwood simple pins radio compatible with KENWOOD Fleetsync series



Speaker Microphone for Kenwood Walkie Talkie

KENWOOD TK-2317/TK-3317/22TK-2360/TK-3360/ TK-2312/TK-3312/NX220/NX320

Type: GPS Speaker Microphone
Operating Temp.: -20°C±2°C ~ 50°C±2°C
Approx. Weight: 200g
Size: 87.0 x 65.0mm

GPS
System GPS
Sensitivity: -159dBm above
Cold Start: 28 seconds in open sky

Speaker
Dimension: Φ40mm
Impedance: 8Ω±15%
Frequency: 680Hz ~ 20KHz
Rate Power: 1W Max 2W
Decibel: 92dB±3dB
Type: Dynamic

TTFF : 28 seconds in open Sky

Microphone
Dimension: Φ6.0 x 5.0mm
Impedance: 2.2kΩ±10%
Sensitivity: -44dB±3dB
Frequency: 50Hz ~ 15KHz
Pattern: Omni-directional

Patent Number

US Patent::
7,668,566/7,783,298/6,912,397/6,941,147
Taiwan Patent:
M338507/M350183/M315917/I252705/I 248771
China Patent:
ZL 200720139535/ZL200620120732/ZL200620118447X
ZL2003201299906



Speaker Microphone for Walkie Talkie -GPSMic for GPSMic for Kenwood simple pins radio compatible with Fleetsync series
