  • BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP
BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP
BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP
BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP
BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP
BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP
BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP
BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP

BEST PRICE!!! POWERGEN Electric Start Keyway Shaft Air Cooled 2 Cylinder V2 Motor Diesel 22HP

Share on (1627114745):


Price:

Quantity:


Product Overview

Description


Product Description

Product Application

The V-twin 2 Cylinder Diesel Engine 22HP can work as engine for Tractors, Motorcycles and Water Pumps, as well as Diesel Generators.


Note: The engine can be shipped without Muffler and Fuel Tank.

\t
Specifications of Diesel Engine 22HP
\t
Model No.
\t
BD2V86FE
\t
Engine Type
\t
Air-cooled, 4-stroke, V-twin 2 Cylinder, Direct Injection
\t
Bore x Stroke (mm)
\t
86x72
\t
Displacement (cc)
\t
836
\t
Compression Ratio
\t
20:1
\t
Peak Power (HP/RPM)
\t
22/3600
\t
Lowest speed @ zero load
\t
<1300
\t
Rotation
\t
Anti-clockwise (PTO Side)
\t
Fuel Type
\t
0#, -10#, -20# diesel
\t
Fuel Tank Capacity (Liter)
\t
12
\t
Fuel Consumption (g/kW.H)
\t
270
\t
Lub. oil Type
\t
CD Grade or SAE 10W-30 15W-40
\t
Lub Oil Capacity (Liter)
\t
2.3
\t
Lubrication System
\t
Forced and Pressure Splashed
\t
Starting System
\t
Electric/Key Start
\t
Center Height (mm)
\t
155
\t
Dimensions (LxWxH)mm
\t
550 x 391 x 460
\t
Net weight (Kgs)
\t
70
Diagram and Shaft
Complete Engine

* Internal 8 Amp alternator with regulator               * Runs on any type diesel fuel
* Equipped with muffler and 12 liter fuel tank         * Gear reduction electric starter
* Two glow plugs for cold weather starting             * One year factory warranty on parts

Applications

Diesel Generator 10KW or 12KW

The diesel engine 22HP or 25HP can work as the engine for diesel generator 10KW.

Fire Fighting Water Pumps

The 2-cylinder diesel engine 22HP or 25HP is ideal for fire fighting water   pump.

Tractors or Motorcycles

The diesel engine 22HP or 25HP can work as engine for tractors and motorcycles.

Packing
\t
Packaging
\t
Size (mm)
\t
650 (L) * 450 (W) * 720 (H)
\t
Gross Weight
\t
84Kg
\t



Packaging Details
\t


1) Inner Packaging: Polybag & Foam
2) Outer Packaging: Wooden Case
3) Wrapping tape
Engine Assembly Line
Certifications
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
