sunset solar water heater cost

Product Overview

Description

low cost solar geyser

non-pressurized solar water heater with galvanized steel or colourful steel outer tank and support.

Specifications:


1.Outer tank: colourful steel or galvanized steel
2.Inner tank: SUS304-2B or 316 food-grade stainless steel  thickness≥0.4
3.Sealing Ring: Excellenrt Silica gel material. life is twice longer than common Silica gel.
4.Vacuum tuber: High-efficient  vacuum tube
*High-Efficient heat-collection function: New generation of vacuum tubes, use molecular nanotechnology, greatly enhance heat-absorption by 20 percent, higher water temperatures.
*Adopts the international advanced film-coating technology, solar thermal conversion rates extremely high, absorbing heat even if the cloud weather.
*Vacuum tube strictly choose high-borosilicate glass 3.3 so that it has low coefficient of thermal expansion and higher intensity. Hail-resistance:25mm
5.Insulation: 55mm polyurethane  keep heating  do with aging  the cell is small and uniform reasonable density excellent insulation
6.Frame: thicker galvanized steel , Anti-corrosive.and Anti-ultraviolet, installed in the slope and flat place freely.Strengthen hail-resistance. Angle:20-80 degree.Through oxidation process.It increase wind resistance.,life is longer than common frame.  Beautiful appearance.
7.Automatic operation: Digital controller shows water temperature and water lever,water loading automatically ,heating automatically ,controlling automatically.

Model:

Model	Ligthing (m2)	Vacuum Tube			Supply hot water(L/D)	20/40" container
		diameter	length	No.
IPYM420-1500/47-12	1.26	Ø47mm	1500mm	12	70	80/195
IPYM420-1500/47-18	1.80			18	100	58/135
IPYM420-1500/47-24	2.49			24	130	46/108
IPYM420-1500/47-30	3.15			30	160	37/90
IPYM470-1500/47-12	1.26	Ø47mm	1500mm	12	90	68/166
IPYM470-1500/47-18	1.80			18	130	52/126
IPYM470-1500/47-24	2.49			24	168	41/98
IPYM470-1500/47-30	3.15			30	210	32/80
IPYM470-1800/58-12	1.68	Ø58mm	1800mm	12	100	56/136
IPYM470-1800/58-18	2.57			18	150	38/95
IPYM470-1800/58-24	3.40			24	200	32/76
IPYM470-1800/58-30	4.32			30	250	26/63
