Industrial Microwave egg tray drying machine

Product Overview

Description





Application Range of  Industrial Microwave egg tray drying machine :



Microwave egg tray drying machine is a modern high-tech production equipment, has proven high efficiency, low energy-consuming  and low maintenance during years of practice, it has changed the traditional heating and drying egg tray heat transfer method. It need not preheating and heat transfer, directly heat the egg tray from the inside to the outside at the same time. heating uniformity, no coking phenomenon.

But the traditional hot air heat transfer due to temperature is high or low, resulting in coking and different angles of the endogenous phenomenon, cannot be uniformly heated.

Microwave egg tray drying machine can be continuous production, simple operation, can be single equipment operation, save labor,drying fast. Dried egg tray has good looking appearance, no deformation.

Features:

1. Improve the quality of products, no cracking, no shrinking, no deformation , insect-resistant;

2. Drying and insecticidal proceed at the same time, good effect;

3. Drying fast, low energy consumption, lower the cost, increase efficiency;

4. No environmental pollution, particularly applicable to the factory which is located in the strict environmental requirements area. .

  Industrial microwave Cell egg tray drying machine Features :



microwave has rapid heating, uniform heating,save energy/efficient,safety/harmless,work continuously,improve working conditions greatly etc features,it’s widely used in the paper products processing of drying stereotypes bend resin agglutination etc .Apply to paper,paper tube, honeycomb cardboard,environmental protection paper bowl,egg tray,cardboard box, oil butter paper,Kraft bag,paper yarn compound bag etc fast drying.Another application in paper products and wood pulp processing is glue adhesion and curing.This not only can use cheap adhesives made into high quality carton box,but also can’t worry about rai and cloudy trouble,and make high quality resin compound board.









Parameter of   Industrial microwave  egg tray drying machine

Model	TL-100
Frequency	2450±50MHz
Speed Transmission Belt	0-10m/min  (Adjustable)
Rated input power(KVA)	140kw
Microwave output power(KW)	100kw
Rated Dehydration(kg/h)	100~140
Rated sterilization capacity(kg/h)	1400~1600
Size L*W*H(mm)	15200*1665*1750
