Polyethylene Buoy

Buoy type

  3000 mm

Float material:

UV-stabilize Virgin Polyethylene. Polyethylene

The lantern height focus from water base:

5000-8050mm   adjustable

Average draft/nominal draft :

2200-2400mm or as required

Reserve buoyancy :

4100kgs min w/o chain

Total weight of buoy without anchoring :

Around 2680kgs - 3000kgs

Visibility wide surface:

7 - 10 m2 min as required

Free board:

1200-1350mm

Tolerancy of dimension deviation:

+/-20mm

The bouys wall thickness:

15-20mm

Area below the water: min

72kg/cm

Net buoyancy (without mooring system)

Around 8200kgs

Reserve buoyancy from the weight without mooring line :

50%   MIN
