New design R32 gas DC inverter 9000btu 12000 btu 1 ton wall mounted split type factory prices air conditioner

Product Overview

Description

12000 btu 1 ton wall mounted split type air conditioner

1:Use the known brand rotary type compressor;

2:High Efficient Internal Thread Copper pipe;

3:LED digital display, Fault Self-Diagnose Code Showing;

4:Self-diagnose capability, error code showing;

5:Intelligent Defrost,Independent Dehumidification,Sleep Mode,Quiet Operation;

6:Low Voltage Startup,Auto—protection,Auto Restart;

7:Optional Refrigerant:R410A & R22 ;

8:Optional Voltage:220V/50Hz  & 220V/60Hz;

9:8:With CE,RoHS ,ISO9001, ISO14001 standard;

10:Sales Area:Mid East,Africa ,South America,Europe,Asia,Central America,Oceania;





Type			9000btu	12000btu	18000btu	24000btu
Control type			remote controller	remote controller	remote controller	remote controller
Declared  cooling capacity		W	2600(940~3320)	3400(1000~3770)	5130(1250-5920)	6810(1830~7810)
Declared heating capacity		W	2610(940~3380)	3420(1000~3810)	5230(1350-6280)	6870(1850~7930)
Pdesignc		W	2600	3400	5100	6800
SEER declared		W/W	6.5	6.5	6.3	6.5
Energy  Class			A++	A++	A++	A++
SCOP Average declared		W/W	4.0	4.0	4.0	4.1
Energy  Class(Average)			A+	A+	A+	A+
Annual energy consumption	Cooling	kwh/a	140	183	283	366
	Average	kwh/a	735	840	1575	1878
Moisture removal		Liters/h	0.9	1.1	1.5	1.8
Indoor sound power(H/M/L/Mute)		dB(A)	50/43/35/32	50/43/35/32	53/48/43/37	54/51/48/40
Outdoor  sound power		dB(A)	60	60	65	67
Indoor sound pressure(H/M/L/Mute)		dB(A)	40/33/25/22	40/33/25/22	43/40/35/27	44/41/38/30
Outdoor  sound pressure		dB(A)	50	50	55	57
Electrical Data
Power supply			220-240V~/50Hz/1P	220-240V~/50Hz/1P	220-240V~/50Hz/1P	220-240V~/50Hz/1P
Voltage Range		V	165~265	165~265	165~265	165~265
Operating current	Cooling	A	4.0(1.2~6.3)	4.7(1.5~6.7)	7.2(1.7~10.8)	8.9(2.3~12.5)
	Heating	A	4.1(1.2~6.5)	4.5(1.5~7.0)	7.3(1.7~12.0)	9.0(2.3~13.7)
Power consumption	Cooling	W	750(240~1230)	1010(290~1320)	1530(330-2250)	1980(410~2800)
	Heating	W	752(240~1280)	948(290~1400)	1550(340-2350)	2050(420~3000)
