DZB400/900 B ROLL PERFORATION GARBAGE BAG MACHINE/ROLL PERFORATION PLASTIC GARBAGE BAG MAKING MACHINE

Product Overview

Description

Name:Computer Control High-speed Vest Rolling Bag making Machine/bag machine/plastic machinery

Features:
This Full Automatic High Speed Vest Rolling Bag Making Machine  is a specially-designed point-cut rolling dual-purpose for vest & flat bags,is controlled by a computer, the step(servo) setting length system reduces the sealing-cutting dimensions errors, and the installation of photoelectric eyes track help make the position of figure of printing bags accurately, the computer numerical control can be selected to adjust the length of bag the machine will automatically stop and sound a warning if there is something wrong with the printing bags.
Use:
The high and low density polyethylene film bags produced by the machine are applied to shopping in the supermarkets, shops and markets.



Main Technical Variables:

Model	DZB-500	DZB-600	DZB-800
Max.Width of bag-making(mm)	400	500	700
Max.length of bag-making(mm)	1200	1200	1200
Bag-making Thickness	0.008-0.15	0.008-0.15	0.008-0.10
Speed of bag-making(pc/min)	140-200	40-120	40-120
Power of motor(kw)	1.1	1.1	1.5
Electric Heating power	1.2	1.6	2.2
Packing Dimensions(L x w x h)mm	3600X1200X1700	3400X1300X1700	3600X1500X1700
Machinery weight (kg)	800	900	100
