aluminum honeycomb sheet

Product Overview

Description

aluminum honeycomb sheet



FLORES aluminum honeycomb sheet(panel) is a sandwich panel bonded with aluminium face material and with a core in aluminium honeycomb. It offers high mechanical properties and good fire performances.



FLORES aluminum honeycomb sheet Structures:



TOP ALUMINIUM SKINS Thickness in mm:

0,5 - 0,7 - 1 (standard)

Special thickness according to customers’ requirements



ALUMINUM CORE

Hexagonal cells, Alloy series 3003

Diameter in inches: Ø1/4”, Ø3/8”, Ø1/2”, Ø3/4”

Foil thickness: from 50 to 70 microns



BOTTOM ALUMINUM SKINS Thickness in mm:

0,5 - 0,7- 1 (standard)

Special thickness according to customers’ requirements



On request: Special alloys, treatments and coating with RAL colors



FLORES aluminum honeycomb sheet Specifications  :

Total Thickness: 6mm-200mm

Standard thickness: 6mm, 15mm, 20mm, 25mm, 30mm, 35mm, 40mm

Standard size: 1220x2440

Other size on request



Colors: RAL colors

Min. order quantity: 10m2

Quality Warranty: 20 years



Company prodution capacity: 1000000m2 / year

Company Certificate: ISO9001:2008, ISO14001:2004

Fire-rated certificate:En13501-1;  BS476 part4, 6&7, Chinese B1



Other service: supply extrusions and assembly accessories!!
