Muster Press Tricot Warp Knitting Machinery With EL System and Cut presser

Product Overview

Description

High Lights of tricot warp knitting textile machinery for fashion fabrics with EL,and cut presser

• 4 shafts E-positive yarn feeding system: Set the yarn feeding parameters through PC touch screen (equipped with the servo motors from Japanese brands)


• 3 guide bars EL: Pattern processes can be input through USB, active and saved with PLC (equipped with the servo motors from Japanese brands)


• Equipped with embedded needles


• Main motor frequency conversion, CVT


• Touch screen operation


• Standard: Q/HCZZ001-2007


• Suitable products: Fashion shell fabric, Mesh fabric

Technical Specification of tricot warp knitting muster press  machinery with cut presser

• Needle-type: Bearded needle


•


  Machine gauge: E12 or E14





• Products width allowance:  2159 mm (85")


• Number of guide bars: 3


• Method of warp let-off: E-positive, customized beaming parameters (EBC)


• Beam size: 14”


• Flange Diameter: φ356


• Shaft Diameter: φ102


• Aperture: φ70


• Beam Width: 356


• Density tuning method: Digital controlled, PC touch screen operation (EBA)


• Braiding method: EL, digital controlled presser


• Main shaft speed: 700 RPM (frequency control)


• Main motor: 2.2 KW


• Yarn feeding motor: 0.5 KW×2 pieces


• Shogging motor: 0.75 KW×4 pieces


• Outline dimension:85”: 2900mm (Length) x 2000 mm (wide) x 2600mm (height)


• Total weight: Approximately 3500 Kg


•
