Автоматическая бесконтактная автомойка машины и струи воды мойка для машины!
- Category: Car Care & Cleanings >>>
- Supplier: Yancheng,Dayang,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Main features
1. Use technology of high pressure jet wash to remove the dirt of car surface.
2. Equipped with automatic sensor system and rocking nozzles.
3.Controlled by PLC provides very reliable and robust control system, failure warning
and suspension automatically.
4.On line testing, control of operating condition and process parameters, realizing
integration of mechanic and electricity.
5.Optional under chassis wash system and water recycling system.
Specifications
Dimension of the machine----------------- 1500(L)x3500(W)x2800(H)mm
Max. washable car size--------------------- 5500x1950x2000 (LXWXH)mm
Length of the rail:----------------------------8000mm
Moving speed of the machine------------------- 6m/min
Max. water consumption(per car)----------------250L/car
Water pump station----------------------------------5.5KW
Total Power--------------------------------------------- 9KW
Power supply-------------220V/380V, 50/60 HZ, 1 phase/3 phase
The weight --------------- 1.5T
The install size----------- 8000X4000X3200(LXWXH)
Related products
Our Services
Warranty will continue to be valid for a period of 12 months provided the following warranty conditions are observed.
Warranty Conditions:
1. This warranty is valid from the date of receiving equipments.
2. This warranty is given for the benefit of the first owner only and claims by parties other than the original purchaser will not be recognized, as the warranty is not transferable.
3. This warranty is only valid when the product has been used in accordance with the Installation, Operation, Maintenance and Instruction Manual and by a competent person trained in its use.
4. This warranty does not apply to damage or deterioration, which is caused by human.
5. During warranty period, shipping cost of replacement products or parts are our responsibility.
6. Beyond the warranty period, we provide spare parts to customers at factory cost.
