Ethernet to V.35 interface converter ,V35 protocol converter

Product Overview

Description







We are professional maufacture of fiber optical wireness transmissin equipments.

The audio signal ,video signal RS232/RS485/RS422 asynchronous data,2/4 lineE&M ,switch signal, Ethernet singal(2M) all transmit on the fiber optic cable .



Wholesale and retail



1.  OEM manufacture



2.   New product.



3.    MOQ1pcs for our stock products.



4.   Delivery: within 3days for small order.



5.    High quality,Competitive price, Best price.



Overview





1. FC-PCEV35 Protocol converter is based on FPGA, providing one DTE or DCE V.35 interface and 1 channel Ethernet interface to achieve 10/100Base-T Ethernet data transmission on the E1 channel.


2. It is a high performance, self-learning Ethernet bridge.


3. This device is the extension device of Ethernet , using network(DDN,ISDN,ATM)that provide V.35 channel to achieve local and remote Ethernet interconnecting at a lower cost.


4. The device has inter-set loop test function to facilitate the project launching and daily maintenance.



Feature

• Based on self-copyright IC


• The Ethernet interface supports jumbo frames (2036 Bytes);


• Inter-set dynamic Ethernet MAC address (4,096) with local data frame filtering


• Ethernet interface supports10M/100M, half/full duplex auto- Negotiation and AUTO-MDIX (crossed line and straightly connected line self-adaptable );


• Have Ethernet monitor self-reset function, the equipment will not dead


• Have two Loop Back Mode: V.35 Loop Back (ANA),Ethernet interface Loop Back(DIG),


• Have pseudo random code test function, easily line opened, can be used as a 2M BER Tester


• Provide 3 clock types: Internal clock, External clock,E1 line clock;


• Support SNMP Network Management;

 Technical Parameters



u V.35 Interface



Interface rate	0-10M(DTE),0-2048K(DCE)
Interface Standard	Compatible with V.35 Standard
Connector	DB25
Connect Mode	DCE/DTE
Clock Type	G.703 restored clock, Internal clock



u Ethernet interface (10/100M)



Interface rate	10/100 Mbps, half/full duplex auto-negotiation
Interface Standard	Compatible with IEEE 802.3, IEEE 802.1Q (VLAN)
MAC Address Capability	4096
Connector	RJ45, support Auto-MDIX



u Power



Power supply	AC180V ~ 260V;DC –48V;DC +24V
Power consumption	≤3W



u Dimension



Desk-top	216 X140 X31 mm(WXDXH)
19 inch	483X138X44 mm (WXDXH)



u Working environment



Working temperature	-10°C ~ 50°C
Working Humidity	5%~95 % (no condensation)
Storage temperature	-40°C ~ 80°C
Storage Humidity	5%~95 % (no condensation)





Network Application
