snap on connectors / tyco 2 pin connector / battery connector

Product Overview

Description

Snap on connectors / tyco 2 pin connector / battery connector



Rated current :50 / 175 / 350 AMP

Voltage :600 V DC
Color : As your request ( red , green , blue , black and white )

Certificate : UL

Material:UL94V-0 PC housing and silver-plated copper contact









Name:	Forklift Connector / forklift battery connector
Model:	SC50 / SC175 / SC350
Current:	50A / 175A /350A
Voltage:	600V DC
Pole:	2
Interface:	Male and female
Color:	red, black, blue, green, white
Contact Material:	Silver-plated Copper
Material:	Polycarbonate
Wire:	customized
Housing material:	polycarbonate
Certification:	UL,ROHS,CE
Spring material:	stainless steel
Application:	supplies power to amateur radios and battery backup sources for the setup





 Mainly export to Australia , European , America, Korea ………….



1.      Terminal size of SC50 : 10/12 AWG / 8 AWG / 6 AWG



2.      SC175 of 4 AWG / 2 AWG / 1AWG /  0/1 AWG



3.      SC350 of 2/0 AWG  /  3/0 AWG  /  4/0 AWG  /  300 AWG



4.      with matched handle and cover ;













We are a Chinese manufacturer-Uchen factory , specialized in kinds of plug ,socket , switch , adapter. battery connector / forklift connector. EV charger plug and socket .and so on . also provide OEM and ODM service;



If you interest any ,please contact us freely .Thanks in advance;
