Diamond Jet Pulverizer /powder making machine

Product Overview

Description

Synthetic Diamond micron powder Pulverizing machine



General



 Diamond Dedicated Grinder is specially designed, based on Jet Mill Classifier, according to the physical properties and processing requirements of diamonds: to reduce over-ground powder and improve the rate of finished products.

Features



Diamond Dedicated Grinder adopts the most suitable flow field calculated by our Hydromechanics Numerical Similitude Software. It makes a breakthrough in particle acceleration technology and a great improvement of grinding efficiency, saving energy and reducing over-ground fineness;



1. Inter-particle attrition of materials resulting in little wear and no iron contamination, free of high-cost and cleaning;

2. With total dry processing, better particle size distribution of diamond powder is obtained when one-time processing is finished;

3. Our original External End Face Sealing Technology (patent for invention) obtains greater fineness and avoids oversized particles;

4. Capacity of shaping particles;

5. Multi-use of one machine due to its alterable and compact structure and also can be used  as classifier alone;

6. Decreased wear and long service life due to sound flow filed design

7. Fully enclosed way of feeding reduces the loss of materials;

8. Omniseal negative pressure operation, without dust pollution;

9. Easy handling and low noise emission (≤70dBA).



Applicaitons

Super hard materials: diamond, cubic boron nitride (CBN) etc.



Technical Data



Model	Air Flow	Max Feed Size (mm)	Product Size (d50μm)	Capacity (kg/h)	Power (kw)
LNJ-6A	1m³/min	≤1mm	1-75µm	0.2-2kg/h	9.5kw
LNJ-18A	3m³/min	≤5mm	1-75µm	5-15kg/h	23.7kw
LNJ-36A	6m³/min	≤5mm	1-75µm	20-80kg/h	47.5kw
LNJ-60A	10m³/min	≤5mm	1-75µm	30-150kg/h	79kw
LNJ-120A	20m³/min	≤5mm	1-75µm	50-200kg/h	137kw
LNJ-240A	40m³/min	≤5mm	2-75µm	100-500kg/h	291kw







Powder shaping





Personalized design to solve the affairs on grinding and classification.
