SJ 120 China promotion professional Waste pp pe Plastic Recycling Machine with two units of extruders
- Category: Recycle Washing Line >>>
- Supplier: Ruian City Sanyuan Plastic Packing Machinery Co. Ltd.
Share on (1695780890):
Product Overview
Description
SJ-120 China promotion professional Waste pp pe Plastic Recycling Machine with two units of extruders
Product Description
Product Description
1.SJ-120 Double-stage Waste Plastic Regenerative Pelletizer is equipped with two units of extruders, which is advantaged to moisture evaporation, and with even and smooth regenerative plastic granules.
2.plastic recycling extruder is also equipped with automatic temperature control system, which is suitable for HDPE. LDPE waste plastic regenerative palletizing.
Main specification of the recycling machine
Output: 50-60 kg/h
Applicable raw material: HDPE/LDPE, PP materials
Power supply: 380v, 50Hz 3 Phase
Material of screw and barrel: Alloyed high-quality steel 38CrMoAlA with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment
Gear box: Hard Surface Gear
Automatic temperature controlling system
Including water-cooling device made of stainless steel
Including granule cutter
Main Extrusion Unit
Main extruder
Main motor :18.5kw
Screw Diameter: Φ 120mm
Screw ratio: L/D 28: 1
Auxiliary extruder
Auxiliary motor: 11kw
Screw Diameter: Φ 90mm
Screw ratio: L/D 28: 1
Heating
Main Technical Parameters: | |||
Model type | SJ-100 | SJ-110 | SJ-120 |
Diameter of Screw Stem | Φ 95mm | Φ 105mm | Φ 115mm |
Major Diameter Ratio of Screw Stem | 18: 1-22: 1(L/D) | 18: 1-22: 1(L/D) | 18: 1-22: 1(L/D) |
Rational Speed of Screw Stem | 10-110rpm | 10-110rpm | 10-110rpm |
Main Motor Power | 11kw | 15kw | 18.5kw |
Main Motor Power | 7.5kw | 7.5kw | 7.5kw |
Max: Output | 50kg/h | 60kg/h | 80kg/h |
Machine Weight | 0.8t | 1.2t | 1.5t |
(L*W*H) Overall Dimensions(L*W*H) | 6000*2250*1500 | 6600*2350*1500 | 6800*2550*1550 |
Free Spare Part
No. | Spare parts name | Quantity | Notes |
1 | Temperature meter | 1set |
|
2 | Electric Sensor | 2 pcs |
|
3 | Heating ring | 3 pcs |
|
4 | Tool box | 1set |
|
5 | English manual | 1pc |
|
Company Information
Packaging & Shipping
FAQ
Q1: Are you a factory or trading company
A1: We are a factory, we can guarantee our price is first-hand, very cheap and competitive.
Q2: How does your factory do regarding quality control?
A2: All the products will be 100% checked before the shipment.
Q3: When can I get the price?
A3:Usually we quote within 24 hours after we get your inquiry.
Q4: How could I get a sample?
A4: if you can not buy our product in your local area, we will ship a sample to you.You will be charged a sample price plus all related shipping costs.Express delivery charge depends on the quantity of the samples.
Q5: What is the price of shipping?
A5: Depending upon the port of delivery, prices varies.
