| Module Type | 50W-P |
| Cell Type | 156mm*54mm |
| Number of Cells | 4*9pcs |
| Dimensions | 556*670*35mm (21.89*26.38*1.38inch) |
| Peak Power (Pmax) | 50W |
| Module Efficiency | 16.07% |
| Cell Efficiency | 16.4% |
| Power Tolerance | ±3% |
| Open Circuit Voltage(Voc) | 21.06V |
| Short Circuit Current(Isc) | 3.13A |
| Max Power Voltage(Vmp) | 18V |
| Max Power Current(Imp) | 2.78A |
| Max System Voltage | DC 600V |
| Operating Temperature | -40°C~85 °C |
| Nominal Operating Cell Temp. | 47±2 °C |
| Temp. coefficient Isc(TK Isc) | 0.06%/ °C |
| Temp. coefficient Voc(TK Voc) | -0.34%/ °C |
| Temp. coefficient Power(TK Pmax) | -0.42%/ °C |
| Series Fuse Rating | 10A |
