High Capacity Steam Jet Mill for Processing Petroleum Coke
- Category: >>>
- Supplier: Mianyang Liuneng Powder Equipment Co. Ltd.
Share on (1699572350):
Product Overview
Description
Steam Jet Mill for Petroleum Coke
General
The grinding of Steam Jet Mill for Petroleum Coke is achieved by using superheated steam as processing medium. The superheated steam is speeded up into high-velocity airflow that accelerates inter-particle collision of materials through annular supersonic nozzles. The ground materials will be classified by turbo air classifier, and then qualified powder will be collected by the posterior collecting system while the unqualified will be returned to grinding zone to be ground again. The steam in the whole system keeps superheated, and total dry processing is employed in producing.
Features
- Energy saving, using superheated steam as driving force, few process of energy conversion;
- Obtaining higher fineness, possible to grind some materials down to submicron or even nanometer range;
- Few quick-wear parts & low maintenance costs;
- Safe processing and high combustion efficiency;
- Low cost and large-scale ultrafine powder processing.
Technical Data:
Model | Gas Consumption | Max Feed Size | Product Size | Capacity |
LNGS-200 | 200kg/h | ≤3mm | 1-74µm(adjustable) | 50-200kg/h |
LNGS-1000 | 1000kg/h | ≤5mm | 1-74µm(adjustable) | 100-1000kg/h |
LNGS-2000 | 2000kg/h | ≤5mm | 1-74µm(adjustable) | 500-4000kg/h |
LNGS-3000 | 3000kg/h | ≤5mm | 1-74µm(adjustable) | 1T-7T/h |
LNGS-6000 | 6000kg/h | ≤5mm | 1-74µm(adjustable) | 2t-10t/h |
LNGS-10T | 10t/h | ≤5mm | 1-74µm(adjustable) | 5t-20t/h |
Applications
fly ash, titanium dioxide, coal powder, petroleum coke, carbon black, graphite, mica, talc, quartz, barite, kaolinite, diatomite, aluminium/ magnesium hydroxide, metallic oxide and agrochemicals etc.
Office & Plant
Mianyang Liuneng Powder Equipment Co., Ltd. is located in Mianyang - China Science and Technology City, long-term commitments to
ultra-fine grinding, precision classifying, particle morphology control and equipment Research and Development.
Our company respects independent innovation, the pursuit of excellence in entrepreneurship, it has taken the forefront of powder industry in jet milling, grading technology. Customized design & solve industrial problems are our purpose, thousands of production lines had been supplied to clients from all over the world.
LNPE has full-scale, advanced technology and equipment powder processing test center, includes laser Particle Size Analyzer, electro microscopy, etc ,and our product is customized to meet user’s requirements of different particle size.
Specific surface tester: Quantachrome Nova 3000
Electron microscopy (sem) scanner: Carl Zeiss
Particle size analyzer: Malvern sprayanalyzer MS 2000, Beckman Coulter LS 200.
Patents for Inventions &
Certificate
LNPE has numbers of patens for inventions and utility patents which are widely used in ultra-fine grinding, precision classifying, particle morphology control
Exchanges & Cooperation
LNPE respects independent innovation, the pursuit of excellence in entrepreneurship, it has taken the forefront of powder industry in jet milling, grading technology. Customized design & solve industrial problems are our purpose, thousands of production lines had been supplied to clients from all over the world.We have customers from all over the word, eg. France,Germany,Russia,South Korea and Japan.
