Good Quality led 24v power supply high voltage 20a 480w dc power supply

Model

S-500-12

S-500-15

S-500-24

S-500-36

S-500-48

Dc output voltage

12V

15V

24V

36V

48V

Rated output current

40A

33A

20A

14A

10A

Output current rage

0~40A

0~33A

0~20A

0~14A

0~10A

Rated Power

480W

495W

480W

504W

480W

Wave and noise

150mVp-p

150mVp-p

150mVp-p

150mVp-p

200mVp-p

Inlet stability

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load stablity

±1%

±1%

±0.5%

±0.5%

±0.5%

Efficiency

78%

82%

84%

85%

87%

Adjustable range for DC voltage

±10%

±10%

±10%

±10%

±10%

AC input voltage range

AC100~240V 47~63Hz;240~370VDC

Input current

5A/230V

AC INnrush current

Cold-start current 46A/230V

Overload proctection

105%~150% Tpye:Foldback current limiting Reset: auto recovery

Setup rise hold up time

200s,100ms,20ms

Withstand voltage

Input and output internal 1.5KVAC,Input and enclosure 1.5KVAC,Output and enclosure 0.5KVAC

Isolation resistance

Input and output internal Input and enclosure,Output and enclosure 500VDC/100MΩ

Working temperature

-10°C~+50°C

Overall dimension

238*124*65mm

Safety standards

Meet ULGB4943 UL60950 EN60950 requirement

EMC standards

Meet EN55022 GB9254 class A requirement

Weight

1.35Kgs
