Aoca 110/220VAC Single Output Type S 600 12 12V 50A 600W Switch Power Supply

Model

S-600-12

S-600-15

S-600-24

S-600-36

S-600-48

Dc output voltage

12V

15V

25V

36V

48V

Rated output current

50A

40A

25A

16.7A

12.5A

Output current rage

0~50A

0~40A

0~25A

0~16.7A

0~12.5A

Rated Power

600W

600W

600W

600W

600W

Wave and noise

240mVp-p

240mVp-p

240mVp-p

200mVp-p

300mVp-p

Inlet stability

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load stablity

±1%

±1%

±0.5%

±0.5%

±0.5%

Efficiency

78%

82%

84%

85%

87%

Adjustable range for DC voltage

±10%

±10%

±10%

±10%

±10%

AC input voltage range

AC100~240V 47~63Hz;240~370VDC

Input current

7A/115V 3.5A/230V

AC INnrush current

Cold-start current  18A/115V 36A/230V

Overload proctection

105%~150% Tpye:Foldback current limiting Reset: auto recovery

Setup rise hold up time

200s,100ms,20ms

Withstand voltage

Input and output internal 1.5KVAC,Input and enclosure 1.5KVAC,Output and enclosure 0.5KVAC

Isolation resistance

Input and output internal Input and enclosure,Output and enclosure 500VDC/100MΩ

Working temperature

-10°C~+50°C

Overall dimension

238*124*65mm

Safety standards

Meet ULGB4943 UL60950 EN60950 requirement

EMC standards

Meet EN55022 GB9254 class A requirement

Weight

1.35Kgs
