Uv sterilizer cabinet for cap sterilizing use
US $300.00-$950.00
Aseptic Tubular Ultra High Temperature Sterilizer Automatic UHT Sterilizer For Milk Juice beverage filling line
- Category: Sterilizer >>>
- Supplier: Zhangjiagang Fillex Beverage Machinery Co. Ltd.
Share on (1700004884112):
Product Overview
Description
Product Description
Automatic Pasteurizer UHT Sterilizer (Ultra High Temperature Treated)
The blended material, prior to be filled, needs to be sterilized with the most common process, thermal sterilization. According to different product characteristics, the subsequent matching of the filling process and the shelf life, ultra-high temperature treated (UHT) can be selected, usually heating to 130 °C for more than a few seconds.
Heat exchanger may be in the form of a plate, a tube, a bellows, or the like. For products with pulp particles or high viscosity, tubular exchangers must be used to prevent clogging. At the same time, the tubular heat exchanger also has a more powerful pressure bearing capacity.
For cloudy beverage or milk based juice, we recommend tubular UHT; for a clear juice, plate UHT can be used.
Application:
UHT Sterilizer Machine is used for pasteurism, ultra-pasteurism and ultra-high temperature sterilization of liquid.
1-- Mainly used for aseptic filling packing types products, such as tetra paper brick, tetra paper pillow, aseptic soft plastic bag, aseptic PET bottles, especially used for liquid milk and juice.
2-- It can be used to do continuous sterilizing and be connected to homogenizer and water removing equipment.
1-- Mainly used for aseptic filling packing types products, such as tetra paper brick, tetra paper pillow, aseptic soft plastic bag, aseptic PET bottles, especially used for liquid milk and juice.
2-- It can be used to do continuous sterilizing and be connected to homogenizer and water removing equipment.
Process:
Material--→balance tank45~55°C→heating95°C→overheating120°C (120 insulation 15s)→cooling95°C→55~65°C (outlet temperature can be adjusted according to process requirements) →Filling (or reflux)
UHT Sterilizer Advantages:
1. High heat efficiency, 90% of heat reused.
High heat effciency, 90% of heat can be reused after the product be processied.
2. Automation control, with self CIP and SIP system
It is of high degree automatic, can autonatically control the CIP cleaning, self sterillizing, and the whole procedures steps,all the procedures are recorded and controllable.
3. Temperature difference between the product and the heating mediun is small, so the heating is gentle.
It is of precise and reliable sterlizing temperature control; all the affecting factors such as steam pressure, steam flow rate, product flow rate are all controlled.
4. Sterilize thoroughly and fully.
Features:
2. Combined Italian technology and conform to Euro-standard.
3. Great heat exchange area, low energy consumption and easy maintenance.
4. Adopt mirror welding tech and keep the smooth pipe joint.
5. Auto backtrack if not enough sterilization.
6. Liquid level and temp controlled on real time.
7. CIP function.
8. Can be working together with homogenizer, Vacuum Deaerator and degasser and separator, etc.
9. Independent Siemens control system. Separate control panel, PLC and human machine interface.
Product Paramenters
Model | FL-UHT-1.5 | FL-UHT-3 | FL-UHT-5 |
Capacity(L/H) | 1500 | 3000 | 5000 |
Inlet temperature | 25-40°C | 25-40°C | 25-40°C |
Holding temperature time(s) | 120-180 | 120-180 | 120-180 |
Sterilizing temperature | 95-121°C | 95-121°C | 95-121°C |
Outlet temperature | 25-35°C | 25-35°C | 25-35°C |
Tower water inlet temperature(°C) | -30 | -30 | -30 |
Steam pressure | 0.5Mpa | 0.5Mpa | 0.5Mpa |
Steam consumption | -150Kg/h | -210Kg/h | -280Kg/h |
Compressed air pressure | 0.6Mpa | 0.6Mpa | 0.6Mpa |
Compressed air consumption | 50L/H | 50L/H | 60L/H |
Overall dimensions(L*W*H) | 7000*2000*2000 | 7000*2000*2000 | 7000*2000*2000 |
Weight | 1700Kg | 2000Kg | 2200Kg |
Details Images
Company Profile
Fillex Team
One-stop Solution
With systems from FILLEX for filling non-sparkling water, you can rely on our high quality and ideal hygienic conditions combined with maximum cost and energy efficiency. Whichever container shape you prefer - we will find the best solution for your requirements.
Customer Service
More than 60 exporting countries, serving more than 180 customers, such as Thailand, Myanmar, Russia, South Africa, Turkey, Argentina, USA, Canada, Mexico, Australia, etc.
We already have 3 branches: Indonesia, Dubai, Saudi Arabia.
Exhibition
Packing&Shipping
Our Services
Factory Layout Design
The Sample Service
1.We can send you the video of the running machine.
2.Your are welcome to come to visit our factory,and see the machine running.
Customized Service
1.We can design the machine according your requirements,at the same time we will give you our prefessional suggestion,as you know we have been in this industry for many years.
After-sales Service
1. We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly.
2. When you finish the Preparation conditions,our fast and professional after-sales service engineer team will go to your factory to install the machine, give you the operating manual, and train your employee untill they can operate the machine well.
3. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
4. We provide one year quality warranty，and supply spare parts at low cost for life span after sale. We keep the original
drawings of spare parts, so it can match with the rest part of machine.
5. Well-traned & experienced staff are to answer all your inquiries in English and Chinese.
6. 24 hours/365 days online technical service.
7. 12 Months guarantee and life-long technical support.
8. Your business relationship with us will be confidential to any third party.
9. Good after-sale service offered, please get back to us if you got any questions.
Quality Control
We have the single quality department,that make sure the material of the raw materials is good,and ensure the machine running smoothly.
1.We can send you the video of the running machine.
2.Your are welcome to come to visit our factory,and see the machine running.
Customized Service
1.We can design the machine according your requirements,at the same time we will give you our prefessional suggestion,as you know we have been in this industry for many years.
After-sales Service
1. We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly.
2. When you finish the Preparation conditions,our fast and professional after-sales service engineer team will go to your factory to install the machine, give you the operating manual, and train your employee untill they can operate the machine well.
3. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
4. We provide one year quality warranty，and supply spare parts at low cost for life span after sale. We keep the original
drawings of spare parts, so it can match with the rest part of machine.
5. Well-traned & experienced staff are to answer all your inquiries in English and Chinese.
6. 24 hours/365 days online technical service.
7. 12 Months guarantee and life-long technical support.
8. Your business relationship with us will be confidential to any third party.
9. Good after-sale service offered, please get back to us if you got any questions.
Quality Control
We have the single quality department,that make sure the material of the raw materials is good,and ensure the machine running smoothly.
FAQ
Q1: Are you a trading company or a manufacturer?
A1: We have our own factory for many years,can give u best service.
Q2: What's your guarantee if we buy your machines?
A2: We offer you high quality machines with 1 year guarantee and free spare parts for 1 year. Meanwhile our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.
Q3: When can I get my machine after I paid?
A3: We will deliver the machines on time as the date we agreed both side.
Q4: How can I install my machine when it arrives?
A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.
Q5: What's the delivery time?
A5: 30-45 days after the T/T deposit or L/C.
Q6: Do you provide customized service?
A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.
A1: We have our own factory for many years,can give u best service.
Q2: What's your guarantee if we buy your machines?
A2: We offer you high quality machines with 1 year guarantee and free spare parts for 1 year. Meanwhile our engineers have rich experience and have gone to more than 50 countries for installation and commissioning.
Q3: When can I get my machine after I paid?
A3: We will deliver the machines on time as the date we agreed both side.
Q4: How can I install my machine when it arrives?
A4: Our engineer will go to your side as soon as you get your machines ready for testing and teaching your technicians how to run the machines.
Q5: What's the delivery time?
A5: 30-45 days after the T/T deposit or L/C.
Q6: Do you provide customized service?
A6: We can design the machines according to your requirements (material, power, filling type, container and etc), at the same time we will give you professional suggestion by many years industrial experience.
