80L 100L 120L 150L 180L 200L 240L Calentador Solar Water Heater best selling in Peru Chile Columbia
- Category: Solar Water Heaters >>>
- Supplier: Haining,Ousikai,Industrial,And,Trading,Co.,Ltd.
Share on:
Product Overview
Description
Model | vacuum tubes | Absorb area | Capacity | suitable for | container | container | |||||||
pcs | size | M2 | tank(L) | tube(L) | system(L) | person | 20'GP | 40'HQ | |||||
NPS-8 | 8 | 58*1800 | 1.064 | 71 | 24 | 95 | 1-2 | 85 | 210 | ||||
NPS-10 | 10 | 58*1800 | 1.33 | 87 | 30 | 117 | 2 | 73 | 179 | ||||
NPS-12 | 12 | 58*1800 | 1.596 | 103 | 36 | 139 | 2-3 | 64 | 157 | ||||
NPS-15 | 15 | 58*1800 | 1.995 | 128 | 45 | 173 | 4 | 53 | 128 | ||||
NPS-18 | 18 | 58*1800 | 2.4 | 152 | 54 | 206 | 5 | 46 | 109 | ||||
NPS-20 | 20 | 58*1800 | 2.66 | 168 | 60 | 228 | 5-6 | 42 | 101 | ||||
NPS-24 | 24 | 58*1800 | 3.2 | 200 | 72 | 272 | 6 | 34 | 81 | ||||
NPS-30 | 30 | 58*1800 | 4.02 | 250 | 90 | 340 | 8-9 | 29 | 68 | ||||
NPS-36 | 36 | 58*1800 | 4.78 | 299 | 108 | 407 | 10-11 | 22 | 53 | ||||
80L 100L 120L 150L 180L 200L 240L Calentador Solar Water Heater best selling in Peru Chile Columbia
Material: Food grade SUS304-2B stainless steel
Thickness:0.4mm-0.5mm
Diameter: Normally 360mm
2.Outer tank
Material: SUS201 stainless steel or painted steel
Thickness:0.31mm-0.5mm
Diameter:Normally 460mm
3. Insulation layer
Material:High density polyurethane foam
Thickness :50-65mm
Heat preservation :72 hours
4.Frame
Material: SUS201 stainless steel or painted steel or aluminium alloy
Angle:0-45 degree
5.Vacuum tube
Material:high borocilicate 3.3 glass tube
Thickness: 1.6mmTube size:58*1800mm
6.Optional accessories
Electric heater, magnesium bar, intelligent controller
7.Warranty
Wholesystem:5 years
The main products of our company:
Non-pressurized solar water heater;
Heat pipe solar water heater;
Separate pressurized solar waer heater;
Heat pipe solar collector;
Non-pressurized solar collector;
Pool solar collector system;
Solar hot water system;
Supporting solar energy.
Non-pressurized solar water heater;
Heat pipe solar water heater;
Separate pressurized solar waer heater;
Heat pipe solar collector;
Non-pressurized solar collector;
Pool solar collector system;
Solar hot water system;
Supporting solar energy.
What is the difference between Non-pressurized Solar water heater and pressurized type?
1. The pressurized hot water loses less energy than the normal one.
2. The pressurized can be used in cold winter,
3. strong pressure water makes your bathe more comfortable.
Why choose Ousikai?
1. We have both vacuum tube factory and water tank factory for more than 8 years, professional.
2. We provide 10 years warranty for the whole system. Others normally with 5 years.
3. Keep the delivery time exactly.
Payment Terms:
1) 100% T/T in advance (sample)
2) L/C at sight
3) 30% Deposit in advance and balance should be paid before shipment based on you nominate the forwarder
4) 30% Deposit in advance and balance should be paid after receiving the B/L copy.
1. The pressurized hot water loses less energy than the normal one.
2. The pressurized can be used in cold winter,
3. strong pressure water makes your bathe more comfortable.
Why choose Ousikai?
1. We have both vacuum tube factory and water tank factory for more than 8 years, professional.
2. We provide 10 years warranty for the whole system. Others normally with 5 years.
3. Keep the delivery time exactly.
Payment Terms:
1) 100% T/T in advance (sample)
2) L/C at sight
3) 30% Deposit in advance and balance should be paid before shipment based on you nominate the forwarder
4) 30% Deposit in advance and balance should be paid after receiving the B/L copy.
