Model | STP-12x2 | STP-16x2 | |||||
Capacity | Dry Weight/Laundry Capacity 10:1(kg) | 16 | 12 | 16 | 15 | ||
Dry Weight/Laundry Capacity 9:1(kg) | 18 | 13 | 18 | 17 | |||
Cylinder Volume(L) | 322 | 120 | 322 | 150 | |||
Speed | Cylinder Speed(r/min) | 40 | 45 | 40 | 45 | ||
High-extraction Speed(r/min) | / | 650 | / | 650 | |||
Dehydrating Factor(G) | / | 173 | / | 173 | |||
Electric | Motor Size(KW) | 0.25 | 1.5 | 0.2 | 1.5 | ||
Inverter Power(KW) | / | 1.5 | / | 1.5 | |||
Fan Motor Power(KW) | 0.55 | / | / | / | |||
Dimensions | Cylinder Diameter(mm) | 760 | 670 | 760 | 6760 | ||
Cylinder Depth(mm) | 710 | 340 | 710 | 425 | |||
Door Diameter(mm) | 600 | 506 | 600 | 506 | |||
Distance from central of door to ground(mm) | 1670 | 650 | 1720 | 650 | |||
Cabinet Height(mm) | 2075 | 2075 | |||||
Cabinet Width(mm) | 800 | 800 | |||||
Cabinet Depth(mm) | 1200 | 1200 | |||||
Air Exhaust Size(mm) | 180 | / | 180 | / | |||
Cold Water Pipe Size/Qty(DN/piece) | / | 20/2 | / | 20/2 | |||
Hot Water Pipe Size(DN) | / | 20 | / | 20 | |||
Drain Pipe Size(mm) | / | 76 | / | 76 | |||
Water Working Pressure(MPa) | / | 0.2~0.4 | / | 0.2~0.4 | |||
Weight | Weight(kg) | 438 | 478 | ||||
