ASTM A865 extra strong seamless threaded coupling

Product Overview

Description



ASTM A865 extra strong seamless threaded coupling



1)- Size: 1/8"~6"

2)- Thread: BSPT, DIN,NPT,  (ISO7/1, DIN 2999, ANSI B1.20.1),

3)- Standard: EN 10241, DIN 2986, ASTM A865,

4)- Materials: ASTM A53, ASTM A106, ST33, Q235

5)- Finishing: Hot Dipped Galvanized, Electro Galvanized, Black

6)- Type: Heavy type, Medium type, Light type, Full & Half

7)- Shape & Appearance: Full length, Half length with Beveled ends, Full internal threads

8)- Color: Black, White (Zinc plated, Galv., Electro-plated)

9)- Usage: Convey Water, Gas, Oil, Steam, Construction Materials etc.

10)-Mechanical Properties:

Tensile Strength ≥320N/mm2

 Yield Strength ≥195N/mm2

 Elongation≥ 20%

11)- Hydraulic Test: Working Pressure: Max 1.5Mpa

12)-Test Pressure: Max 2.5Mpa

13)-Production Capacity: 60000 MT per Year

 14)-Lead Time: Within 30 Days if quantity not exceed 10x20' Containers.



Seamless steel socket, Merchant Coupling
Size	1/8"~6"
Thread	DIN, BS, NPT, Metric, BSPT, BSP, NPS(ISO7/1, DIN 2999, ANSI B1.20)
Standard	EN 10241, DIN 2986, ASTM A865
Materials	ASTM A53, ASTM A106, EN10216, S235, DIN1629, ST37-2, ST33, Q235
Finishing	Zinc plated (Hot Dipped Galvanized, Electro Galvanized, Baked galvanized), Black, Chem black, Natural finishing.
Color	Black, White (Zinc plated, Galv., Electro-plated)
Type	Heavy type, Medium type, Light type.
Length	Full length, Half length
Thread type	Full internal threads (Full female threads)
Shape	Beveled ends (Chamfer ends), Plain ends, Saddle end.
Usage	Convey Water, Gas, Oil, Steam, Construction Materials etc
Chemical Composition max	C 0.25%, S 0.35%, P 0.09%
Mechanical Properties	Tensile Strength ≥ 320 N/mm2
	Yield Strength ≥195 N/mm2
	Elongation ≥ 20%
