atex iecex emergency tube linear led ATEX T8 explosion proof fluorescent light LAMP

Product Overview

Description



  explosion proof fluorescent light

1.LED Explosion Proof Light 20W/25W/35W
2.LED Explosion Proof Light with CE&RoHS approval. Bridgelux LED chip, high quality with 3 years warranty.
3.Patented design for heat dissipation to ensure life of light source up to 50000 hours.
4.Low power consumption while high light efficiency, power consumption just 20% as much as high pressure sodium lamp, mercury lamp at the same luminous condition, it saves energy more than 75% than that traditional light.
5.Die casting aluminum housing, with anti-static and anti-corrosion coating,high explosion-proof degree of flameproof type; dust-proof, waterproof; lens made of bulletproof PC which is thermal resistance,corrosion resistance, high light transmission.
6.Advanced quadratic light distribution design result in high uniformity of illumination and good lighting quality, clear lighting effect without a double image.
7.Beautiful appearance, several types of installation methods available.



  explosion proof fluorescent light



Features:

1. Increased safety type of explosion proof grade, 95-265V alternating current and 24V direct current for option

2. Integrated type of tube, adopt SMD LED on aluminum base, make aluminum base completely attached to heat sink which composed of lamp body to make sure excellent heat dissipation, lead to long lifetime.

3. Adopt silicon encapsulated sealed power supply whose body made of aluminum alloy, put it inside of aluminum body and closed attached to heat sink to make sure heat dissipated from power supply.

4. Cover made of high quality PC which enjoy high-strength, impact resistant, hot resistant, corrosion-resistant.

5. Completely sealed to waterproof, dust-proof, corrosion-resistant.

6. Smart appearance, equip with two mounting brackets,it can be installed easily.





Power Consumption	20W	30W	40W	50W	60W
Input Voltage	220V AC(applied for 95-265V)
Frequency	50Hz/60Hz
Explosion-proof Grade	Ex embⅡC T6
Corrosion-proof Grade	WF2
IP Grade	IP66
Light Effect	≥90lm/W
Beam Angle	120°
Power Factor	≥0.90
Cable Entry	Φ8~Φ10mm
Installation Height	2~5m
Ambient Environment	Temperature:-30°C-55°C; Humidity:10-90%RH(25°C)
Storage Temperature	-40°C-60°C
Lifespan	50000Hs
Material	Aluminum Alloy&PC
Dimension	L850XW136XH91.5mm		L1295XW136XH91.5mm
Net Weight	4.5KG		6.9KG

  explosion proof fluorescent light
