1. Temperature, acidity and density in automatic control, the products always stay in the best conditions of production, quality more stable.
2.Plating liquid fluctuation recycle, uniform all the time.
3.Possible Adjust the cathode anode distance, always maintain the best condition
4.Brightener can be plus at any time, the content is held constantly. 5.Online filtering, plating solution clean, improve product quality, reduce the consumption 6.Plating liquid recycling solution, make the solution loss to a minimum.
1.Cover area (1.3 * 5 meters), single machine 2 shift 3 - 4 tons per 24 hour meter (2.6 mm wire)
2.Pay-off scribble and automatic stop device (national patent application no. 201020282524.1) , wire will not break because of the input scribble.
3.adopt galvanized liquid recycle use system (national patent application no. 201020282533.0) to effectively control loss of plating liquid, reduce material consumption.
4.Sulfuric acid electrolytic adding special additives, solve the pollution of acid mist.
5.Three level water cleaning after plating, change per shift , return plating liquid to plating tank completely,save water by 95%
6.Automatic control the plating temperature, acidity, solution cycle , makes the best process conditions
7.Using separate energy-efficient high-frequency rectifiers; the current, pickling, electroplating, noninterference drying in separate stable working.
8.Change frequency control of motor speed,capacity adjustable, zinc coated thickness can reach more than 50 g/m2
9.All electrical appliances a stop button to open, flexible and convenient.
technical parameters :
1. rectifier power:5kw per hour
2. every lines has 2 pcs of wire and wire close unit
3. every wire close unit capacity is 1.5tons 24hours continous working (2.6mm wire in 20g/mm2 zinc quantity)
4.no water consumption 5
.zinc block consum:4-5kgs/ton depend on zinc quantity
