Automatic Vacuum Forming and Cutting Machine

Product Overview

Description

Automatic Vacuum Forming and Cutting Machine

I.Parameters

Parameter	XC800-1200
Available material	PP,PE,PET,HIPS,GPPS,PVC,EPS
Formed area(mm)	800×1200
Formed depth(mm)	150mm
Formed speed(cycles/min)	≤18
Max. sheet width(mm)	850
Sheet Thickness (mm)	0.2-1.5
Total Power(KW)	110
Air wastage(Mpa)	0.6-0.8
Max. speed(moulds/min)	≤60
Dimension(mm)	18000x3000x2800



II.Function

11. Forming and strentching by positive and negative presure
2. Continuous cutting and large forming area
3. Servo-system to feed, form, cut, count and stack.
4. Adopting advanced PLC controller and touch screen
5. Fitting for producing PP/PE/PET/GPPS/HIPS/EPS/PVC plastic products, like milk cup, jely cup, ice cream cup, one-off cup, instant noodle bowl, fast food box and food box

III.Main Fittings
1.Electric Fittings: Japan Yamatake Temperature Control Meter, Schneider

Pushbutton, Selector Switches, Pilot Lights, Contactor and Thermal Overload Relay, Korea LG Circuit-breaker;
2.Lubricating System: Taiwan Famous Automatic Oiling System;
3.Pneumatic System: Japan SMC;
IV.Some samples

V.Drawing



VI.Certification

VII.The relative patent
