200mA High Frequency X ray Radiograph Machine

Product Overview

Description

AJ-X160A 200mA High Frequency X-ray Radiograph Machine









Feature



1. It is installed with close-table graphical colorful LCD touch screen and wireless remote control exposure, which makes the operator easy to use.
2. We incorporate the latest compact high-frequency and high-voltage X-ray generator, which ensure superior image quality, while the skin dose is low, to protect the patient better.
3. Adopt the technology of kV and mAs numeral closed loop control, real-time control of the microprocessor, which ensures the accuracy and repeatability of the output dose.
4. Be equipped with radiography parameter of multi-part, multi-posture, multi-body, adult -child physical characteristic, the operator can modify and save the parameter by himself, which makes the operation more conveniently.
5. First high power combined high frequency high voltage X-ray source and high frequency inverter power supply, which can reduce energy loss from outside HV generator and cable. It makes good quality X-ray, beautiful appearance and convenience.
6. Possess multiple automatic protection and fault clue function, which makes the operation safer and more reliable.
7. The radiography table can float in any direction, electromagnetic braking, position the patient more convenience and accuracy.
8. X-ray generator component can move round the axis of X-ray generator, cross arm and Pillar stand , be convenient with side and slanting direction projection and radiography of patient on the stretcher.
9. Be equipped with the chest stand, which is used in the radiography of the head, chest, belly, pelvic cavity, backbone and periphery.
10. Control console of graphic program controlled LCD touch screen is optional, which can set the radiography parameter and exposure in another room.





Standard Configurations



1, new integral radiography table (with pillar)                   one unit

2, combined high-frequency high-voltage X-ray generator         one set

3, Colored LCD touch screen control box                       one unit

4, Control system (with software)                             one set

5, Chest stand (with imported filter grids)                       one unit





Specification

Item	AJ-X160A
Output power	25kW
Power supply	380V 50Hz, Capacity: ≥40kVA
Main inverter frequency	40kHz
X-ray tube	Rotary anode, dual-focus, Large focus: 1.3mm, Small focus: 0.6mm, Anode thermal capacity:212kJ (300kHu) Tube thermal capacity: 900kJ (1200kHu)
Rotary anode speed	3000rpm
Tube current	200mA
Tube voltage	40kV-125kV
mAs	0.4-360mAs
Table radiography grids	Grid density:103L/INCH;Grid ratio:10:1;Focusing distance:120cm;Stationary type:15"×18"
Chest stand radiography grids	Grid density:103L/INCH;Grid ratio:10:1;Focusing distance:150cm;Stationary type:18"×18"
Operation method	close-table graphic program controlled LCD touchable screen operation; wireless remote control exposure

Table size	2000×760mm
Table height	≤700mm
Table transverse movement	≥210mm
Table longitudinal movement	≥325mm
Grids cassette holder movement	≥560mm
X-ray tube assembly center rotation	≥±90°
Rotation of the pillar	4×90°
Axial rotation	0-35°
SID	450-1200mm
Pillar movement along the table	≥1370mm
Limited time of analog light beam opening	About 30s
Film size	5"×7"-14"×17"(Table radiography)
Film size	5"×7"-17"×17"(Chest stand radiography)
Chest stand up and down movement	472~1470mm
