against AK47 steel plate armor ballistic steel plate



Ballistic steel plate technical paremeters

Applications

Armored vehicle, bulletproof vest and helmet, armored equipments,

Chemical

C

Si

Mn

P

S

Cr

NI

Mo

Ceq

compositions

≤0.32

≤1.8

≤1.1

≤0.015

≤0.008

≤1.5

≤1.8

≤0.5

≤0.70

(wt%)

Ceq-carbon equivalent, Ceq=C+Si/24+Mn/6+Ni/40+Cr/5+Mo/4+V/14

Mechanical Properties

Tensile strength

Yield strength

Elongation

Rm, Mpa

Rp0.2, Mpa

A,%

≥1650

≥1400

≥8%

Impact properties

AKV2 (-400C)≥20J (10mmx10mmx55mm test specimen)

*-Average of three specimens, transverse to rolling direction

Hardness range

480-530HB

Testing

Brinell hardness test

EN ISO 6506-1

Each heat treatment individual

Tensile test

EN 10002-1

Charpy impact test

EN 10045-1

t>10mm

Delivery condition

Quenched and tempered as EN10025-6



The size of carton: 560x560x240mm

5pcs/carton

Sample: 7days/per sample

Bulk quantity: according to your quantity



We are a state owned enterprise and the professional in researching bulletproof materials and producing bulletproof products for decades. In China bullet proof factories, only our factory has our own labs for research and testing, so the products quality is under strict control.

We are good at mass production (50000 pcs per month for the vest, 5000-8000 pcs per month for the helmet). Our product material is genuine , the process is excellent. Last but most important, once you book the order, you can come to our factory sampling from each lot to do the field shooting test in our testing lab and get the certificate. All the process can be done in our factory. Only we could promise and do it in China. Of course, we also welcome you to visit our factory before you make your decision.
