OEM AC Coffee Grinder Motor

Product Overview

Description

OEM AC Coffee Grinder Motor



Detailed Product Description



Model		CF93	CF115	CF120	CF180
Eff  [%]		44.8	45.70	53.6	54.77
Output power [W]		93	115	120	180
Input power [W]		207	252	224	329
Rated current [A]		0.91	1.1	1.16	1.55
Rated speed [min-1]		1229	1177	1342	1224
Rated torque [Nm]		0.73	0.93	0.86	1.41
Max torque	[Nm]	1.18	1.42	1.87	1.97
	( / )	1.62	1.52	2.14	1.40
Locked torque	[Nm]	0.70	0.84	0.96	0.96
	( / )	0.96	0.91	1.12	0.68
Min torque	[Nm]	0.78	1.42	1.10	1.19
	( / )	1.07	1.52	1.28	0.84
Locked current [A]		1.08	1.77	2.9	3.02
Voltage/Hz		230V 50Hz	230V 50Hz	230V 50Hz	230V 50Hz
Capacitor		6µF/450V	8µF/250V	8µF/450V	8µF/450V



MOTOR FEATURES:

IP22 enclosure
Class B insulation
Corrosion resistant
High quality lamination steel giving very low iron losses
High quality magnet wire
Vacuum varnish impregnation for superior tropic proof insulation
Industrial type service factors
Rolled steel motor body
Aluminum drive and non-drive ends
Thermal overload protection
Long life capacitors



Quiet operation

Low vibration

Superior life
High strength frame
Reliable in country, city or factory environments
