Product Overview
Description
60Watt PV Solar Panels Aluninium frame charging for Solar camping light
Solar Panel Feature:
1. Nominal 18V DC for standard output.
2. Cable connectors for easy installation.( custom connector DC line/ MC4 connectors/
Alligator clip/SAE ect)
3. Outstanding low-light performance.
4. Splendid aesthetic appearance and easy installation.
5. High efficiency & high stability.
6. Advanced EVA encapsulation system with TPT back sheet to improve product modules
7. Design to meet unique demand of customer.
8. 25 year module output warranty.
Electrical Characteristics
| Model type | 80W | 70W | 60W | 50W | 40W |
| Peak power(Pmax) | 80 | 70 | 60 | 50 | 40 |
| Weight(kg) | 7.02 | 6.29 | 5.52 | 4.82 | 4.09 |
| Dimensions(mm) | 875x670x25 | 775x670x25 | 675x670x25 | 580x670x25 | 480x670x25 |
| Maximum power voltage (Vmp) | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 |
| Maximum power current (Imp ) | 4.58 | 4 | 3.43 | 2.86 | 2.29 |
| Open circuit voltage (Voc) | 21.6 | 21.6 | 21.6 | 21.6 | 21.6 |
| Short circuit current (Isc) | 5.17 | 4.52 | 3.87 | 3.23 | 2.59 |
| Maximum system voltage | DC 1000V | ||||
| Temp.Coeff.of Isc(TK Isc) | 0.045%/℃ | ||||
| Temp.Coeff.of Voc(TK Voc) | –0.34%/ | ||||
| Temp.Coeff.of Pmax(TK Pmax) | –0.47%/℃ | ||||
| Normal Operting Cell Temperature | 45±2℃ | ||||
| Tolerance | 0~3w | ||||
FAQ
Q1 Are you a factory or trading company?
A Yes, we are factory, supplying OEM/ODM service.
Q2 Can you accept OEM service?
A Yes, we can. Qty is not the only standard , more qty, less cost.
Solar panel, over 100pcs
Q3 How about your after sales-service?
A .Guarantee time: 3 years
Q4 How about your payment terms?
Q4 How about your payment terms?
A We accept T/T, LC
Q5 What certification do you have?
Q5 What certification do you have?
A 1.CE, IEC report.
2. According to your need , do the certification or report , if you have a big order.
Q6 How many day about delivery time?
Q6 How many day about delivery time?
A 1. Sample delivered in 3-5 days.
2. Order delivered in 15-20 days.
Q7 Which port shipping goods?
A Ningbo port
