Product Overview

Description

(DFX-23A) mobile suction apparatus   Medical Suction Devices With Battery





DFX-23B·II (AC/DC) EMERGENCY SUCTION UNIT

     DFX-23B·II portable emergency suction unit adopts AC/DC power supply and battery as standby power supply. It can be applied in suctioning secretions, bloods and other substances that cause blocking in respiratory tract, and may also be used in suctioning required in other surgical operations. It is especially fit for first aid in the outdoor circumstances and on ambulance and where there is no power supply. Where there is power failure from electric grid, the AC/DC will switch automatically to ensure normal use.

Features:

This device is suitable for AC and DC power supplies can be connected to car-carried power supply.

This device is able to store and supply power itself, with duration being more than 2 hours.

AC and DC power supplies can be automatically switched over without affecting normal use.

The device is equipped with a imported membrane pump available with long service life.

This device is available with full charge function.

When the device fully charged, the charging will be automatically stopped.

This device is particularly suitable for ambulance and field applications because of its small volume.

This device is equipped with an overflow protection unit to prevent liquid from getting into pump body.







TECHNICAL SPECIFICATION: suction pump mobile



Negative pressure:	≥0.09Mpa(680mmHg)
Air pumping efficiency:	≥20L/min
Capacity of liquid vessel:	1000ml
Range of negative pressure:	0.013MPa~0.09Mpa(680mmHg)
Power supply:	AC220V±10% 50Hz DC 12V
Input power:	150VA
Pump structure:	oil-free self-lubricated pump
Noise:	≤50dB
Work mode:	intermittent load continuous operation



PRODUCT ADVANTAGE: mobile suction apparatus



1.AC/DC,can use in car

2.battery lasts for more than 2 hours

3.AC DC switch automatically

4.imported diaphragm pump

5.indication for battery full charge

6.automatically stop when battery full charge

7.small size and low noise

8.with an overflow protection

9.oil-free pump is maintenance-free
