Stacked Type Small Size High Speed Automatic Flexographic/Flexo Press/Printer

Product Overview

Description

Dear sir,



Pls find our Specification and payment term as below:



Payment	TT/L.C
Delivery	60-120 days



Configuration:

1.The main motor adopts imported inverter to govern  a stepples speed adjustment.

2.Feeding and rewinding are controlled through magnetic particle brake and clutch(Japanese Mitsubishi auto tension controller).

3.Un winder system is controlled by edge guide sensor.

4.Adopt ceramic anilox roller which offers durability, wear resistance and corrosionresistance, also is more efficient on production by reducing the times of changing rollers.

5.The printing units are all equipped with a group of infrared dryers respectively .

6. Each IR dryer device of printing unit is interchangeable to UV dryer.

7.Un winder and re winder  adopt  air core holder.

8.The printing unit can register in 360 degrees. Each printing unit can be independently geared and loosen to have rest of units continue to printing.

9.The roll feeding, printing, UV vanish, auto infrared drying, laminating and rewinding can be processed in one pass. It has characterized by wide application, fast printing speed and high economic efficiency Ink will not contaminate environment. So it is an idea printing machine for the business form, Tag and high end pressure sensitive label.



Model	CRY-320
Printing speed:	50m/min
Printing colour:	5colours
Max.web width:	320mm
Max.printing width:	310mm
Max.unwinding diameter:	600mm
Max.rewinding diameter:	600mm
Printing length:	175-355mm
Precision of chromatography:	±0.1mm
Dimensions:	2(L)x1.1(W)x2.6(H)(m)
Machine weight:	about2200kg
