NF 2100 CABLING MACHINE
- Category: >>>
- Supplier: Shengzhou Nanfeng Machinery Co. Ltd.
Share on (1807446384):
Product Overview
Description
|
TYPE |
Two sides and single layers |
|
|
Overall dimension (L*W*H) |
23450 |
mm |
|
ach section length |
2135 |
mm |
|
Form of spindle driving |
Belt circulating drive |
|
|
spindle |
||
|
Spindle no . |
160 |
Spindle |
|
Each section spindle no. |
16 |
Spindle/section |
|
Section no. |
10 |
Section |
|
Spindle gauge |
265 |
mm |
|
Spindle speed (max) |
10000 Rpm |
rpm |
|
spindle pot |
Φ144 |
mm |
|
Spindle fixture |
Magnetic fixture |
|
|
direction |
S/Z |
|
|
Twist no. |
50-1000 |
Tpm |
|
Material bobbin |
Paper bobbin L 290 or cops :270 |
mm |
|
Cops capacity |
1.5 |
kg |
|
Take up |
||
|
Take up forming mode |
Electronic traverse |
|
|
Take up Bobbin size |
L 220 (max) |
mm |
|
Traverse length |
L 200 |
Mm |
|
Position of single covering |
160 |
Position |
|
take up bobbin weight |
3 |
KGS |
|
Power |
||
|
Intalled power |
15 |
(kw ) |
|
Start mode |
Inverter soft start |
|
|
system |
Computer system |
|
|
Voltage |
380 V 3 PHASE 50HZ |
|
