acrylic polishing machine diamond edge with 1300 or 1600mm length

Product Overview

Description

Acrylic polishing machine applications: It can polish acrylic, organic glass, plastic,etc.



Features,

(1). The diamond tipped cutter holder is mounted onto an inverter controlled, high frequency spindle. The cutter assembly runs across the material on precision linear rails, giving a smooth and accurate polish.



(2). Material to be polished is clamped firmly to the work table of the machine, giving maximum support and rigidity. Multiple pneumatic clamping cylinders can be adjusted for position both along and across the material, giving the ultimate in flexibility for workpiece holding.



(3). Dust collector is optional



(4). Tool’s blade is diamond material.



(5). Save cost. The only consumable part of the machine is the diamond tools.





Parameters of acrylic polishing machine:

Item	Parameter
Model	JC-1300	JC-1600
Max.polishing length	1300mm (51.2inch)	1600mm (83inch)
Max.polishing width	110mm (4.3inch)	110mm (4.3inch)
Worktable dimension	400 *1940mm	400 *22400mm
Machine dimension	1940*1160*1650mm	2240*1160*1650mm
Gross weight	1750kgs	1900kgs
Cutting depth	0-1mm
Polishing degree	0-60°
Cutting spindle power	1.5KW, air cooling
Cutting spindle speed	0-9000rpm
Motor for cutting spindle	Stepper motor
Machine voltage	3 Phase,380V/50-60Hz or 220V



Inner is protective film, outer is plywood case.



1 year warranty excluding the tools.

By sea.



1. Can this machine polish longer material than 1300mm?

Sorry, it can not.



2. What is the lifespan of the diamond tools?

About 800 hours.



3. Can I polish the diamond tools by myself?

Normally,no.



Samples:
