hdpe geomembrane liner

Product Overview

Description

hdpe pond geomembrane liner
waterproof for landfill/fish farm
thickness:0.2-4mm
material:pe

width:4-8m

length:30-200m

tensile strength:14mpa-27mpa
Certification:iso9001



Application:

1.       Environmental protection, sanitation (such as solid waste landfills, sewage treatment plants, power plants regulate pools, industrial, hospital solid waste, etc.)

2.       Conservancy (such as rivers, lakes and reservoirs dam seepage, lost circulation, strengthening, drainage of seepage, vertical heart wall, slope protection, etc.)

3.       Municipal works (subway, underground engineering building, green roof, roof garden seepage, sewage pipe lining, etc.)

4.       Garden (artificial lake, river, reservoir, golf course ponds substrate, slope protection, green lawn water moisture, etc.)

5.       Petrochemical (chemical plants, oil refineries, gas station storage tanks impervious, chemical reactor, settling tank lining, etc.)

6.       Mining (washing, the heap leaching pool, the ash-field, dissolution, the precipitation, the yard, the substrates of tailings seepage, etc.)

7.       Transport facilities (road base reinforcement, Subway, Culvert seepage)

8.       Agriculture (channel, diversion canal, reservoir, reference pool, water storage pond, irrigation systerm seepage)

9.       Aquaculture (intensive, factory farming pond, fish ponds, shrimp ponds lining, sea cucumber circle slope protection, etc.)

10.   Salt (salt crystal pool, brine pool thatch cover, salt membrane, plastic thatch film of salt pond)



Ordinary High Density Polyethylene Geomembrane (GH-1 Type)



Item	Index
Thickness, mm	0.30	0.50	0.75	1.00	1.25	1.50	2.00	2.50	3.00
Density, g/cm3	0.940
Yield strength (MD/CD), ≥N/mm	3	5	8	11	13	16	22	26	33
Break strength (MD/CD), ≥N/mm	5	8	12	17	20	24	34	40	51
Yield elongation (MD/CD), ≥%	/	/	/	11
Break elongation (MD/CD), ≥%	450
Right angle tear strength (MD/CD),≥N	24	40	60	80	100	120	160	200	240
Puncture-resistant strength, ≥N	51	85	125	170	200	250	340	400	500
Carbon black content, %	2.0-3.0





Environmental Smooth High Density Polyethylene Geomembrane (GH-2S Type)
