ZBJ X12 Low cost paper cup machine production line
- Category: >>>
- Supplier: Wenzhou Qichen Industry&Trade Co. Ltd.
Share on (1845324434):
Product Overview
Description
ZBJ-X12 Low cost paper cup machine production line
Model | ZBJ-X12 | ZBJ-X16 |
Paper Glass Size | 3 OZ-12 OZ | 8 OZ~22 OZ |
Raw Material | One-side PE (polyethylene) film coated / laminated paper Ultrasonic machine can be produce single and double pe paper | |
Speed | 60~75 Pcs/min | 50~65 Pcs/min |
Total Weight | 2500KG | 2800KG |
Package Size (L x W x H) | 2700x1300x1700mm | 2800x1350x2100mm |
Working Power | 3.5KW | |
Total power | 6KW | |
Power Source | 380V 3-Phase 50Hz(if special,please info us) | |
Material | 160~350gsm One-side or Two-side PE (polyethylene) Film Coated Paper | |
Air requirement (Buy Comperssor ) | 0.4Mpa(4bar )/Air pressure:0.4Mpa(4bar) Air out-put:0.6m³/Min | |
Making Double PE coated paper cups, need to buy an air compressor Available to make any special size mold and machine We reserve the right to alter specifications without prior notice. | ||
Main features:
| 1. Output is improved: The productivity is improved from 50-60 pcs/min to 60-70 pcs/min |
2,Stepping-motor is used to control the bottom paper feeding, so that the gap between the bottom-paper is controlled within 0.1mm, which can make machine more stable and save raw material. With light eyes under the paper roll, the machine will be stopped when out of bottom-paper, avoiding the waste in paper. |
| 3. Gear drive is adopted to avoid the defect of loose gap of chain drive. |
| 4. We use a self-lubrication system in the machine, which reduces the friction between the parts. So the machine can be maintained without manually fueling. |
| 5. This device adopt non-contact multi-point light control switch (such as in paper holder, glass tube ,bottom paper and so on, according to customer demand). It can detect working situation, then achieve a fault alarm preventing machine from collision, makes the machine more stable and longevous. |
| 6. Paper tube station uses independent cam to handle glass holder. This is advanced in stability and will not make noise when it works. |
| 7. The machine is equipped with gear motor simplifies the complicated system and makes the machine more stable. |
Related Products
About company
Exhibition
Service
loading & shipping
FAQ
1.what's your product range?
Tea cups,coffee cups ,ice cream cups , noodle bowl, KFC bowl etc.
2. What size of the cup /bowls you can make?
We ccan make paper cups/bowls form 2.5OZ-45OZ.
3. Are you a manufacturer?
Yes,we have been in make paper cup machine 10 years.
4. What about the payment term ?
30%T/T in advanced,the rest need paid before shipping
5. What information should i let you know if iwant te get a quotation ?
--Quantity
--What’s the detailed size (top diameter ,bottom diameter,andheight)
--What’s the paper thickness/gsm
6. What’s your advan tages
--10 years experience :We have been in making paper cup machine for 10 years
--Customers all over the world
-- Certificate:CE certificate
-- Fast reply :Our team will reply you soon
--After-sale service :We have a after sale department ,our company can offer you 10years spare parts required
