My company for a long time to operate this product. High reputation,high quality and resonable price.Also, We have a high technical and efficiency of the production line. Welcome friends from all over the world to visit our company.
Size
Detail
Material
Good quality gypsum board; surface is imported PVC film,
back aluminum Foil
PVC gypsum ceiling board's size
595x595 mm 595x1195 mm 600x600 mm 600x1200mm
603x603 mm 603x1212 mm 605x605 mm 603x1210mm
Thickness
6.0mm, 7.0mm, 7.5mm, 8.0mm, 8.5mm,
9.0mm, 10.5mm, 11.0mm, 12.0mm
Weight
7.5mm=5.9kg/sqm,8mm=6.3kg/sqm,
9mm=6.8kg/sqm,12mm=9.45kg/sqm
Quantity/20ft
7mm=4000, 7.5mm=3800sqm, 8mm=3600sqm,
9mm=3200sqm, 11mm=2500, 12mm=2250sqm
Physical
specification
Surface Disposal
PVC film imported and Aluminum foil for back side
Permissible Tolerance
Length≤±2.0mm
Width≤±2.0mm
Thickness≤±0.5mm
Diagonal≤±1.5mm
NRC
0.1-0.3
Unit Area Quality
7mm<6.5kg/m2, 8mm<7.5kg/m2, 9mm<8.5kg/m2
Load at Break
7mm≥110N 8mm≥120N 9mm≥140N
Fireproof performance
According with Chinese standard GB624-1997
Product
characteristic
Environmental, dust and moisture resistant, easy to clean.
Commercial & good for decorative
Flexible suspension system makes each ceiling tile easily installed and disconnected
Easy to match lamps or other ceiling parts
Application
Indoor decoration of super class buildings such as
hotels, restaurants, shopping malls, theaters
dancery, cinemas, stations, auditoriums
offices, sitting rooms, business buildings, electronic workshops,
precision apparatus rooms and industrial or residential buildings.
Pattern
Main Tee 0.225pcs/sqm
Cross Tee11.35pcs/sqm
Butterfly hanger bolt 2pcs/sqm
Cross Tee2 1.35pcs/sqm
L Angle 0.2pcs/sqm
Packaging & Shipping
Packaging and loading
Our Services
1.we can provide you free sample for your test, the post fee we can bear 30% for you.
2.we provide the special customize size and cut service, also the OEM service and so on.
3.after sale, we would like to answer any question you put forward.
Our certificate
FAQ
Delivery port:XinGang,Tianjin,China
Payment method:L/C ,T/T,WU
MOQ:1*20'FCL
Payment term:30% depsoit,70% against the copy of B/L
Delivery time: within 10days after receive the deposit
our laboratory
Company Information
Company Information
Jinzhou Dong Ya Building Materials Co.,Ltd. , a professional company engages in the manufacture of building materials, is located in JinZhou Development Zone, Hebei province, China where is the largest manufacture base of building materials in China..
The company was established in 1996,covers an area of more than 20,000 square meters,now has more than 300 employees and gross investment is more than 12,000,000USD. Up to now,she has ten building materials production lines.
Our company will consistently improve the corporate management level and technical skills in an all-round way by taking advantage of reform, providing customers with best quality and best service.
