| Industrial Fermenter | |
| Company introducation | We Kuangbo is a production enterprise of pharmaceutical, dairy, food and beer-making equipment, alongside biological engineering, chemical containers, and bespoke products. Our products are widely used in beer production, pharmaceuticals, beverage industries, biotechnology and other fields. |
| Usage | It is used for beer fermentation & brewing. It applies in brewing industry. |
| Material | Stainless Steel 304 or 316L |
| Technology & Design | 1. It is made of double jackets with dimple jacket and insulation layer filled with PU which is imported from Japan. |
| 2. Dish top, conical bottom for good fermenting, improving the quality of beer as well as breeding yeast, cylinder body. | |
| 3. As to polish, interior layer and dish top will adopts 3A mirror polish while exterior layer and conical bottom adopts 2B satin polish. | |
| 4. As to transition of interior, we will adopt arc to make sure that there is no dead corner of sanitation. | |
| 5. 10-30% headspace, 60 degree cone, rotating racking arm is designed according to your demands | |
| 6. All clamps valve and fittings except for cold water inlet and outlet which is Tri-clamp. | |
| 7. As to the thickness, we can make it according to your requirement. | |
| Volume | 50-100,000L |
| Advantage | 1.Configuration details can be designed as your requirements |
| 2.Competitive price and also higher quality tank. | |
| Minimum order | One unit |
| Payment term | T/T or L/C |
| Package | Export standard package |
| Market | At home and abroad |
| Fermenter Tank Technical Parameter | |||||
| Working Volume (L) | Dimension of Tank (D*H) mm | Total Height (H) mm | Diameter of Inlet&Outlet (mm) | PU Insulation (mm) | Manway Size (mm) |
| 500 | Dia 800*800 | 1750 | Dia 38 | 50 | 440*320 |
| 1000 | Dia 1000*1200 | 2200 | Dia 38 | 50 | 440*320 |
| 1500 | Dia 1100*1400 | 2500 | Dia 38 | 50 | 550*430 |
| 2000 | Dia 1200*1500 | 2700 | Dia 38 | 50 | 550*430 |
| 3000 | Dia 1400*1700 | 3150 | Dia 51 | 50 | 550*430 |
| 4000 | Dia 1500*2100 | 3450 | Dia 51 | 50 | 550*430 |
| 5000 | Dia 1600*2200 | 3590 | Dia 51 | 50 | 550*430 |
| 6000 | Dia 1700*2200 | 3650 | Dia 51 | 50 | 550*430 |
| 8000 | Dia 1800*2700 | 4350 | Dia 51 | 50 | 550*430 |
| 10000 | Dia 2000*2800 | 4450 | Dia 51 | 50 | 550*430 |
