Sinotruk HOWO 12m 3/12000 литровый реактивный и вакуумный всасывающий танкер для сточных вод, вакуумный всасывающий комбинированный реактивный станок
- Category: Sewage Suction Trucks >>>
- Supplier: Hubei Veldlion Machinery Co. Ltd.
Share on (1857170387):
Product Overview
Description
Product Description
Sinotruk HOWO 12,000 Liter Vacuum Sewage Suction truck
Customerized is acceptable ,pls kindly advise details as below:
a.Tanker capacity :from 1m3 to 22m3 could be choosen;
b.Material of tanker : We could supply carbon steel like Q235 ,or stainless steel SS304
c.Emission standard of engine in your Country
d.If you have your prefer brand ,pls tell us : We could supply Sinotruk ,Dongfeng ,Shacman ,JAC,FOTON ,I-SUZU , etc
e.You can choose left hand drive or right hand drive
Based on these details ,we would choose right style for you !
I.Specification of Sinotruk HOWO 12,000 Liter Vacuum Sewage Suction Truck
| Brand | SINOTRUK HOWO | |||
| Drive type | 4x2 | |||
| Vehicle Main Dimensions | L×W×H(mm) | 8310*2500*3200 | ||
| Wheel base(front/rear) (mm) | 4700 | |||
| Approach/Departure angle(°) | 19/20 | |||
| Weight in KGS | Gross Weight(kg) | 16000 | ||
| Rated Weight(kg) | 8300 | |||
| Curb Weight(kg) | 7505 | |||
| Model | wd615.62 | |||
| Type | 6-cylinder in-line with water cooling; | |||
| 4-stroke direct injection; | ||||
| supercharged cold | ||||
| Horse Power(HP) | 196kw/266HP | |||
| Emission Standard | Euro II | |||
| Gearbox | HW15710, 10 speed forward with 2 reverse, manual | |||
| Front/Rear Axle Load(KG) | 6000/10000 | |||
| Brake | Air brake | |||
| Tire | 12.00R20,6+1 pcs | |||
| Sewage Suction System | ||||
| Tank Volume(L) | 12000Liter | |||
| Tank shape | Cylindrical | |||
| Tank Material | 6mm thickness carbon steel | |||
| Vacuum pump | Brand /Model | Yifeng brand Using Double vacuum pump | ||
| Rotating speed | 500r/min | |||
| Vacuum degree | 400Pa(99.6%) | |||
| Pumping speed | 68L/S x2 | |||
| Suction Depth(m) | More than 6 meter ,with 25m hose | |||
| Tank Tipping angle(°) | More than 45 | |||
| Rear door | Open and closed by hydraulic cylinders | |||
II.More Details of the trucks for your reference
Company Information
COMPANY INTRODUCE
HUBEI VELDLION MACHINERY CO., Ltd is an authorized special purpose vehciles manufacturer.We are specialized in the production of a variety of special-purpose vehicles.
Create value for our customers is our company's concept. Welcome to enquiry from us, Let's our sales team make you more great in this field.
OUR MAIN PRODUCT:
1. Dump Truck/Tipper Truck
2. Fire Fighting Truck
3. Truck amounted Crane
4. Semi-Trailer and Tractor Truck
5. Water Tank Truck/water bower truck
6. Fuel Tank Truck/fuel refulling truck
7. Concrete mixer truck
8. Fecal suction truck/ sewage suction truck
9. Light Cargo Truck/Mini Truck
10. High-altitude operation truck/cherry picker truck
11. Garbage Truck/Compactor Garbage Truck
12. Refrigretor truck
13. LPG Tanker/LPG tanker trailer/LPG skid station
14. LED Dislay Truck
15. Spare parts
Our workshop view
Workshop View
Packaging & Shipping
Packaging & Shipping for trucks
a.Packaging: Naked
b.Heavy trucks cound be shipped by RO-RO /Bulk vessel /Frame
c.Light trucks could be shipped 20ft /40ft container
Our Services
OUR SERVICES
Create value for our customers:
1. more than 200 professional worker to supply high quality products;
2. Own engineer to design according to your request;
3. QC team to control the all production line;
4. Sales team to follow on all details for you;
5. CNCA+CCC+after sales service+quanlity warranty;
FAQ
FAQ
1.Q:How about the warranty?
A:One year
2.Q:Do you have ISO certificate ?
A:Yes , we have,pls contact us to get our certifications.
3.Q:How about the delivery time?
A: It depends on the style of truck ,normally around 30 working days
4. Q:How about shipping ?
A:Big size trucks always shipping by RORO or Bulk ship or flat bed container or open top container,small type can shipping by container ,Pls contact us to get a shipping quotation .
5. Q: How do you control the quality of product?
A:our workers are well trained. Our very product under goes a scrutinizing inspection process.
6. Q: How about your product After-sales service system?
A:Our main export country have accepted after-sales service,some of country used the third department service.
7.Q: Do you accept Custom orders? What’s is your MOQ order?
A:Yes, we do, our MOQ is 1 set.
8.Q: What’s the payment terms?
A:By T/T or L/C at sight ,Western Union
