union/laundry dry cleaning machine price in india
- Category: Industrial Washer >>>
- Supplier: Shanghai Huayi Washing Machinery Co. Ltd.
Share on (1858701529):
Product Overview
Description
Product Description
1.Steam/Electric heating method
1.Based on prevailing 5th Generation specifications.GXZQ series is environmental friendly. Complete closed refrigeration system which enable recycle of Perc solvent.
Low emission. Truly a Green Environment product.
2.Equipped with VFD which allow flexible selection of dry clean and extraction speed to suit the wash items. Fast extraction. Excellent protection for the washed items. Advanced refrigeration system to control the solvent temperature. Variable extract spin speed to meet the requirement of dry clean of leather and other fabrics. Fast drying.low energy consumption.
3.User friendly touch screen control panel. Fault alarms display. Safe and easy to use by operator or maintain by service personnel.
Technical Parameter:union/laundry dry cleaning machine price in india
| model | GXZQ-8 | GXZQ-10 | GXZQ-12 | GXZQ-16 |
| Washing Capacity(kg) | 8 | 10 | 12 | 16 |
| Drum dimension(mm) | 650x450 | 810x390 | 810x435 | 870x500 |
| cooling of distiller/solvent | water | water | water | water/cold |
| numbers of container | 3 | 3 | 2 | 3 |
| capacity of distiller(l) | 62 | 100 | 100 | 190 |
| type of control | automatic | automatic | automatic | automatic |
| number of controlling program | 10 | 10 | 30 | 30 |
| time of cycle(min) | 40 | 40 | 40 | 40 |
| type of heating | steam/electricity | steam/electricity | steam/electricity | steam/electricity |
| power,Kwt | 5.4/45.9 | 6.4/21.4 | 21.4 | 27.8 |
| steam consumption(kg/cycle) | 3.3 | 6.5 | 6.5 | 8.56 |
| water consumption(l/cycle) | 110 | 143 | 172 | 200 |
| air consumption(m3/min) | 0.01 | 0.01 | 0.01 | 0.01 |
| electric power consumption(Kwt.h/cycle) | 0.82/3.1 | 1.3/8.5 | 1.5/9.0 | 1.7/8.5 |
| overall dimension(mm) | 1460x1000x1880 | 1600x1160x2120 | 1650x1160x2120 | 1500x1830x2200 |
| weight(kg) | 950 | 1580 | 1680 | 1950 |
| voltage(v) | 380 | 380 | 380 | 380 |
union/laundry dry cleaning machine price in india
2. Oil heating method:
1. It has high quality recycle working system, including filter, still tank, still cooler, water separator and cleaning tank, which can save solvent (perchloroethylene), more than 99.8% solvent can be recycled, no pollution to the air, no harm to human, keep the room fresh.
2. Main parts with high quality stainless or non-ferrous metals stamping with a mold crafted, using high-temperature galvanizing technology to greatly increase the corrosion resistance of the machine.
3. Fluff collector uses nylon bag on the filter to prevent blockage.
4. High-speed fan can speed up the drying and cooling rate.
5. Heating the solvent by distillation tank sent vapor into the condenser, and then purified solvent.
6. Dry-cleaning oil filter can remove impurities, particles, pigment, to ensure clean dry oil played a significant role in enhancing the quality of laundry, and avoid problems of dyeing other expensive clothing, reduce the number of distillation, make the machine long life.
7. The device combines advantages of brand-name dry cleaning machines in Germany and Italy.
| Model | SGX-8 | SGX-10 | SGX-15 |
| loading capacity(kg) | 8 | 10 | 15 |
| diameter deep (mm) | 330 | 350 | 400 |
| washing speed(r/min) | 45-65 | 45-65 | 45-65 |
| dry speed(r/min) | 1100 | 1100 | 1100 |
| installed power(kw) | 2.6 | 2.6 | 2.6 |
| Rated Voltage(V) | 220/380 | 220/380 | 220/380 |
| Motor Power(kw) | 1.5 | 1.5 | 2.2 |
| liquid pump power rating(kw) | 0.55 | 0.55 | 0.55 |
| dimensions(mm) | 1580X850X1700 | 1580X950X1700 | 1580X950X1680 |
| time for washing(min) | 10-25 | 10-25 | 10-25 |
| Total Weight(kg) | 600 | 650 | 750 |
