Conductive silver paste for chip inductors
- Category: >>>
- Supplier: Dongguan Meiya Chemical Co. Ltd.
Share on (1862014074):
Product Overview
Description
MK-0050 Chip inductors conductive silver paste
Product introduction
MK-0050 Chip inductors low temperature curing conductive silver conductive silver paste main applications:Low curing temperature,high bonding strength,stable electrical properties,suitable for screen printing and so on.
Thermal conductivity at room temperature curing adhesive suitable for welding applications,such as quartz,pyroelectric infrared detectors,piezoelectric ceramics,potentiometers,flash tube and shield,circuit repair,etc.
It can also be used for radio instrumentation industry for conductive adhesive,can also achieve a conductive adhesive instead of solder paste.
Feature
1. Sintering : 780-850℃
2. NTC thermistor ceramic substrates combined with good,
3. After sintering little effect on the resistance value,
4.It can be excellent weldability.
Usage
| Solid content | 65%-70% |
| Density(g/m3) | 2.1-2.3 |
| Viscosity(CPS) | 10,000-20,000(75rpm,25) |
| Coating area | 100-200(cm2/g) |
| Side resistance | (m/ /25.4m) |
| Adhesion | None Stripped |
| Hardness | 2H |
Usage
| Mesh | Stainless steel,or nylon mesh 180-350 |
| Drying conditions | Ventilation baking oven,120-150℃,10-20mins |
| Sintering | 850℃,Peak 10 minutes |
Atmospheric conditions,ordinary sintering furnace (resistance furnace,muffle furnace),tunnel furnace |
Validity and Storage
From the date of manufacture, 12 months. Please stored at a temperature of 5-10 ℃
