JINTAI brand JHX dual movement palm silicon cutting crude oils emulsifier blending mixing machine

Product Overview

Description

JINTAI brand  JHX dual movementpalm silicon cutting crude  oils emulsifier blending mixing machine

  www.drymixer.com

 Zhengzhou Jintai Metal Material Co.,Ltd is an innovative manufacturer for Mixing machine.JIN HE® JHX series double movement mixer is a national patent product and has proprietary intellectual property rights.it is used for the homogeneous mixing of powders or different components with differing specific weights and particle sizes.

Compared with tridimensional mixer,double cones mixer and V type mixer,our mixer has double movement systems(barrel rolls in horizon axis while the blades inside the barrel blends in oblique axis) which means it can mix materials more efficiently and 100% no dead angle. As customers test the innovative mixing machine we created has amazing performance, the advantages of our double movement mixer are

High quality in mixing effect,100% no dead angle

High capacity(the charging rate can reach to 75% for its unique operating system)

Time saving(save 50% time to meet mixing criteria)

Money saving(saving time 50%,electricity 70% and 30% space)

palm oils emulsifier

There is a specially made sealing component between the shaft and the container. When discharging materials, the container revolves within a small arear through button panel to make ribbon blade stir,accelerating the discharging process. All internal components involved in the process of mixing are made of stainless steel.

1. High mixing efficiency, when compared with conventional mixing equipment, mixing time can be shortened by more than 60%, and power consumption can be reduced by 20%-30%;

2.For the mixer has a small turning radius, and low feeding inlet that located directly above, so compared with Vtype mixer, it’s easy to use and has low labor intensity.

Because the discharge opening is designed with gate valve and plus the two pyramidal angles of inclination in the top and bottom of the material barrel, the discharge is very convenient.

3.  For safe operation, this equipment is especially set with double bond of safe mode of operation. Only press the “get ready” button and the “run” button at the same time, the equipment can only be working. Thus puts an end to the unintentionally touching by people.

4. Because this mixer has a comparative small barrel turning radius, it takes a very small room, and has a better security compared with V-type mixer.

5. Since the force generated by the revolving of ribbon blades can push the light powder into the heavy powder, mixing materials with different specific gravity will be much more efficient.







palm oils emulsifier	Barrel  Capacity   (L)	Max Barrel   Capacity (L)	Max Barrel  Capacity (kg)	Barrel    Speed  (r/min)	Blade    Speed (r/min)	Motor Power  (kw)	Size (mm)	(kg)
JHX50	50	35	60	25	50	1.1	1500×620×1000	430
JHX100	100	75	110	23	46	1.1	1700×720×1200	500
JHX200	200	140	240	21	42	2.2	2050×830×1400	660
JHX400	400	280	500	17	34	3.0	2500×1010×1600	910
JHX600	600	420	700	17	34	4.0	2700×1120×1750	1200
JHX600Z	600	420	1000	14	28	5.5	2700×1120×1750	1400
JHX800	800	560	800	14	18	5.5	2900×1200×1850	2000
JHX1000	1000	700	1000	11	22	7.5	3200×1300×2070	2300
JHX1500	1500	1200	1500	11	22	11	3600×1500×2300	2800
JHX2000	2000	1600	2000	11	22	11	3900×1600×2800	3200

....
