Hot sale nitrogen doser machine

Product Overview

Description

Hot sale nitrogen doser machine :

1)Injecting time can be changed

2)Both individual injecting and continuous injected

3)Liquid nitrogen supplying by manual

Equipped:



Air nitrogen pressure request

4-6.9bar(60-100psi)

Liquid nitrogen pressure request:

Below 1.5bar(below22psi)

Suitable for middle and low speed production line,liquid nitrogen injecting control

Two mode:Possessed time delay and speed compensation

Two functions:Possessed individual injecting and continuous injecting, the highest speed of individual injecting can reach to 350cans/min

Equipped power: 85-265vac/100VA

Features:

Precise injecting,stable and reliable

Without cans, without injecting liquid nitrogen

Easy control system,direct viewing

Used Semens PLC



 The Function



Basically having the air (nitrogen and oxygen) in packed bottles/ Cans makes few difficulties which explained here in below:



1)      The life time of the product will decrease due to existing oxygen.

2)      The product will have expansion or contraction due to area temperature such as sunshine, refrigerator or ambient temperature and it can cause deformation of the bottles.

3)      The bottles/ Cans  are not strong enough for labeling and transportation.

4)      Taste, color and freshness of the products will change.

5)      For hot fillings, after the product became cold it can cause deformation of the bottles/ Cans due to contraction.



All above mentioned problems can be solved easily by using our Nitrodoser system.



How it works
