food processing autoclave sterilizer autoclave for sea food in tin can

Product Overview

Description

what is a autoclave?

autoclave is a kind of back pressure vessel, mainly ued to the sterilization of sea food in tin can, glass jar or vegetable in vacuum package.  of course, this kind of autoclave can be also used to other food in glass bottle and platic botles.



autoclave can be called as autoclave sterilizer, or sterilizer. some times people call them retort or retort sterilizer.



Model	GT7CW720
					production capacity	720
(cans/batch)
Pot body size(mm)	Φ900*1500
volume (m3)	1.1
design temperature(0C)	143 0C
operating temperature(0C)	≤138 0C
design pressure(Mpa)	0.3MPa
working pressure(Mpa)	steam≤0.25Mpa  electrical heating≤0.16Mpa
working medium	Salt, water, steam, compressed air
The main pressure parts material	SS303 / SS316 / carbon steel Q235-A
welding coefficient	0.7
corrosion allowance	1mm
Steam inlet diameter	DN40-50
Exhaust diameter	DN32-40
Cool and hot water Connection pipe diameter	DN40-50
Overflow pipe diameter	DN25-50
Water outlet Pipe diameter	DN40-50
Safe valve diameter(mm)	DN25-50
Compressed air diameter(mm)	DN15-20
Adjust mouth diameter(mm)	DN25-40
Steel Thickness (mm)	6(thickness can be adjust according to request)
Total Weight (kg)	700
overall dimension	2000*1450*1232
mm(L×H×W)



our autoclave sterilizer usually packaged in wooden case which is suitable for sea transport
