LED lights assembly line machine/led bulb chip mounter

Product Overview

Description

     This pick and place machine is special for led factory, it's suit for all led lights products: led lamp, led bulb, led tube, led flexi strip light, led street light...We own the led vision pick and place machine technical Independent Intellectual Property Rights. Our factory can provide whole led assembly line machine solutions.





Main features:



1.Platform transmission adopts Japanese Panasonic servo motor, imported motor, ensure mobile platform stability and precision control.



 2. X, Y axis adopt Panasonic servo driver, cooperate with imported linear railway, ensure that performance of high precision, high speed and excellent stability.



 3.Four pieces of high-speed heads work at the same time, greatly improve the equipment performance to price ratio. the nozzle movement up and down fixtures adopts  imported guide rail, high precision, durable for lifetime.



4.Easy to understand way of graphical programming, which greatly improve the convenience of operation, automatic visual auxiliary positioning, positioning is accurate, convenient.



5.Selection of a variety of feeders, can satisfy the requirement of different smd LED  components.



6.Controlled by industrial computer +Self-Designed independent special controller, system stability, simple operation, easy to learn.



7.Software has powerful functions, programming coordinates using numerical and graphical display, coordinates correction and convenient change, graphical display patch schedule production process and components and reput materials is convenient.



8.Programming software using database system, different types of PCB programming can be stored, convenient adjust, new product only need one time  programming, can use at any time in the future.



9.Platform, Y, X can manually move, the movement speed free adjust, can achieve arbitrary point manually to arrive, convenient programming.



10.Updated advancedTai Wan KAIT Inspection system to inspect more accuracy for nozzle adjustment to avoid missing componets .



11. Adopt Taiwan oil free vacuum system, low noise, long life, vacuum pressure constant.



Model	LED-1204TS
Mount head	4 pcs
Max circuit board size	1200*300mm
Max moving range	X axis 1220mm, Y axis 430mm
Max moving range of Z axis	20mm
Stable Mounting speed	18000 cph
Max mount speed	22000cph
Mount accuracy	±0.05mm
Position method	Visual positioning , additive with Visual camera correction(v) -patent
Component available	SMD Components &leds :0603 above like 0603,0805 , 1206,3014,  Resistance capacity parts 0603 -1608,  chip 3528 and 5050, and various kinds of led   meet the SOP ,SOT chip SMT and compatible with all kinds of high power chip
Programme method	automatic Computer graphical programming + visual camera position  With automatic scanning bonding pad function no need manual programming
Belt feeder	8mm, 12mm, 16mm , 24mm and 32mm
Feeder num	Normal 12 pieces ,Most extensions can be placed 14 pieces  feeders
Operation system	WINDOWS XP
Compressed air	Self-patent internal  vacuum device
Weight	700kg
Dimension	2000*800*1250mm (smaller save place)
Power supply	220V,50Hz,1 Kw (save energy)



Packing in polywood case and film.

shipping by ocean or air by your choose.

  We can provide one year warranty and our engineer can send to oversea to provide after sales service.

  Some our customer list:
