2021 new plastic fruit crate injection molding machine
- Category: >>>
- Supplier: Zhangjiagang Shen Zhou Machinery Co. Ltd.
Share on (1912879888):
Product Overview
Description
For plastic fruit crate injection molding machine
Injection Moulding Machine SZ-5500A
Clamping Force: 550Tons
Space Between Tie Bars: 810mm×810mm
Screw diameter | mm | 80 | 85 | 90 |
Screw L/D ratio | L/D | 22.3 | 21 | 19.8 |
Shot weight | gram | 1948 | 2200 | 2466 |
Injection capacity | cm3 | 2141 | 2418 | 2710 |
Injection pressure | Mpa | 188 | 167 | 149 |
Theoretical injection rate | g/s | 427 | 482 | 541 |
Plastic capacity | g/s | 80 | 100 | 118 |
Injection stroke | mm | 425 | ||
Screw torque | N.m | 5170 | ||
Max screw rotate speed | r/min | 150 | ||
Clamping force | ton | 550 | ||
Opening stroke | mm | 820 | ||
Space between tie bars | mm | 810×810 | ||
Mould height | mm | 350~820 | ||
Max daylight | mm | 1640 | ||
Ejector force | ton | 15 | ||
Ejector stroke | mm | 210 | ||
Ejector quantity |
| 13 | ||
Oil pump motor | kw | 55 | ||
Pump pressure | Mpa | 16 | ||
Heating power | kw | 33 | ||
Machine size | M | 8.4*2.2*2.6 | ||
Machine weight | ton | 23.5 | ||
Oil tank capacity | L | 1000 | ||
International designation |
| 5500-4040 | ||
