Vertical Mounted Magnetic Water Float Level Switch for Humidifier

Product Overview

Description

Vertical Mounted Magnetic Water Float Level Switch for Humidifier

1.long working life 2.stable performance 3.easy mounting 4.multi points control





Level sensor  MR0840-P

 Movement explaination:When the float ball rises or falls with the liquid to the level of the switch, The magnetic force of magnet which inside of the float ball will cause the reed switch to turn ON. When the float ball move away from the reed switch, the reed switch will turn OFF.

























Model		MR0840-P
Installation		Top or bottom perpendicular instal
Mounting dimension		M8
Operating characteristic		N.O/N.C  (optional)
Material  Specification		Electrical  Specification			Physic Specification
Float ball	PP	Contact form	1A	2A	Min shock: 30G on board
Float body	POM	Max contact rating	10W	50W	Min Vibration: 1.5mm (10-55HZ)
Cap nut	POM	Max switching voltage	100VDC	220VDC	Temp Rating: -10-+85°C
O-ring	Silicon	Max breakdown voltage	200VDC	300VDC	Max pressure: 0.2MPa
E-ring	POM	Max switching current	0.5A	1.5A
Filling	EPOXY(ROHS)	Max carry current	1.0A	3A
Wire	UL1007/UL1015 22AWG /24AWG	Max contact resistance	100Ω	100Ω
		Working Life	100,000,000



Application

Water fountain,air cindition,humidifier,bathroom equipment,sale machine,oil tank and chemical liquid level control.It will be widely applied in motor vehicles,industrial equipment,agricultural equipment and household appliances in the future.



  Package

       Standard plastic bags and cartons, also we can provide customized design for all kinds package.
