DIN Standard AAAC All Aluminum Alloy Conductor

Specifications

1.All Aluminum Alloy conductor(AAAC conductor)
2.ISO9001-2008 passed
3.Good price and fast delivery

ZHENGZHOU JIN HANG HIGH -TECH CO ,LTD ,Belong to JinShui Cable group(the subsidiaries are zheng No,2 Cable Factory, Zhengzhou No,2 Cable Electrical Co,Ltd, Henan JinShui Cale Co,Ltd . Zhengzhou jinhang High -Tech Co,Ltd),Mainly specialized in cable\\s R&D,manufacture and distribution , and contributes to promoting Chinese excellent wire &cable products with p;rice in the worldwide market .

As a professional exproter in chinese cable industry , we take the lead in obtaining ISO9001,CCCand certificate for products exempetion from inspection awarded by Chinese govement.  Which meet standard of GB ,IEC,BS,DIN AND etc .in order to gurantee quality ,the process and manufacture of all of our product are complied with or excess international , relative national standards.

Nowadays, Our partner relationship spreads all over Asia,Mid- East,South European, Central,Americam South America area etc  etc .  A stable and close cooperation  had been founded between us and some wold famouse companies such as PLN in Indonesia , Unicable in Singapore, Riyadh Cable Group in Saubia. It will be everlasting to satisfy each our client with good quality and excellent service . And we always insist on our principle”Honesty,Fair, Perfect, Efficiency. Welcome friends all over the world and gain a mutual progress together in the prosperity future !

e can supply this conductor according to different recognized standards, such as IEC61089, BS215, BS EN 50182: 2001, ASTM B231, CSA C49, DIN480201, JIS C3109, customer special specification also can be satisfied.

Construction:

Aluminum alloy 1350-H-19 wires, concentrically stranded about a steel core. Core wire for ACSR is available with class A, B, or C galvanizing; "aluminized" aluminum coated (AZ); or aluminum-clad (AW). Additional corrosion protection is available through the application of grease to the corrosion or infusion of the complete cable with grease.

Specifications:

ACSR bare conductor meets or exceeds the following ASTM specifications:

B-230 Aluminum Wire, 1350-H19 for Electrical Purposes

B-231 Aluminum Conductors, Concentric-Lay-Stranded

B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR)

B-341 Aluminum-clad Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AW)

B-498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ)

B-500 Zinc Coated and Aluminum Coated Stranded Steel Core for Aluminum Conductors, Steel Reinforced (ACSR)

Notes:

Resistance is calculated using ASTM standard increments of stranding and metal conductivity of 61.2% IACS for EC (1350) and 8% IACS for steel. AC (60Hz) resistance includes current dependent hysteresis loss factor for 1 and 3 layer constructions.

Current ratings are based on 75oC conductor temperature, 25oC ambient, 2ft/s wind, 96/watts/sq. Ft sun, 0.5 coefficients of emissivity and absorption
