Sell Concrete Tube Making machine/Cement Pipe forming machine Good Price

Product Overview

Description

Sell Concrete Tube Making Machine/Cement pipe Forming Machine Good price









Working Principle:

This XG series Concrete pipe machine is with simple structure.The Suspended roller passes through the pipe mould.Driving by the motor,the transmission shaft will drive the roller rotating at the regulated speed.Because of the friction force between the roller and stop ring at the two ends of mould ,the pipe mould will be drove rotating at the same direction as the roller.

By manual feeding concrete or conveying machine,the concrete mixture into the mould will be adhere to the inner wall of mould,and become solid,intensity at major function of the roller compressing force and Centrifugal force,and form the standard quality pipe.

Features:

1. 1.    Wide Production Range:Inner Diameter from 200-2500mm,length 1-4 m.


2. 2.    Different Pipe end joint:Flat end,Male&Female end,Spigot&Socket end,


3. 3.    High efficiency,short production time,every pipe needs several minutes,With hard dry casting concrete,high intensity,and better strength,


4. 4.    No polluted slurry discharge,environment friendly,also lower noising,


5. 5.    Our CO2 Arc Welding,and Plasma Cutting machine promise higher quality.

Technical Details:

Item	XG600	XG1500	XG2000
Pipe Diameter	300-600mm	800-1500mm	1500-2000mm
Pipe Length	1-4m	1-4m	1-4m
Roller Diameter	118mm	227mm	325mm
Roller Material	45#Seamless Steel tube with wall thickness 40-100mm
Motor Power	VF-15-23KW	VF-37-55KW	VF-75-132KW
Rotation Speed	140-230 r/min	100-200 r/min	80-120 r/min
Production time	3-5 mins	6-10 mins	10-15 mins











Shanghai Oceana Construction Machinery CO., Ltd is a leading manufacturer and supplier in the Precast Concrete machinery, with R&D, manufacturing workshop, professional sales Team and service.

Our major products are: Water drainage concrete pipe machine and moulds; Pre-stressed Concrete cylinder pipe machines, also the pre-stressed concrete electric pole and pile machine line and steel moulds. Besides we also supply the wire cage welding machine, concrete mixing plant, and other equipments. Again, we provide the factory layout design, machine  proposal, manufacturing, installation & commissioning, worker training, trial production, one-stop service.

Since founded, our company has insisted on the principle of “ Customer First, Faithful Management”. We supply our customers with High Quality product, Reasonable Price,Good after sale service. With customer’s trust and Support, Our machines have been sold to Australia, New Zealand, Vietnam, Nigeria, Algeria, Iran, Mexico, Ecuador, Sri Lanka, and Malaysia.

Look forward for the cooperation with you! Welcome you visit us!
