HannStar HSD084ISN1 A00 lcd display HSD084ISN1 A00 lcd panel

Product Overview

Description



HannStar HSD084ISN1-A00  TFT 8.4  HSD084ISN1-A00 60pin





Panel Brand: HannStar

Panel Model:    HSD084ISN1-A00

Panel Type:A-SI TFT LCD panel

Panel size:8.4inch

Resolution:800(RGB)*400

Display mode: TN,Normally White, Transmissive

Surface:Antiglare, Hard coating(3h)

Brightness:400cd/m2(Typ.)

Contrast Ratio:600:1(Typ.

Display colors:16.2M(6-bit + FRC)

Response Time:2/6 (Typ.)(Tr/Td)  (ms)

Viewing Angle:75/75/60/70 (Typ.)(CR≥10)

Lamp Type:7S2PWLED

Signal Interfance:TTL (1 ch, 8-bit)

Input voltage:3.3V (Typ.)

Working Temperature:-20°C~70°C

Storage Temperature:-30°C~80°C







Codition:A+100% new and original

 Warranty:3-days returned purchase;90-days warranty, doesn't include shipping



  We have many LCD Panels in stock, if you need other models,For more information Pls freely contact us anytime
