Product Overview
Description
china leading brand mini belt conveyor
Product Description
Belt Conveyor
The belt conveyor is the most ideal high-efficiency continuous conveying equipment for minerals. According to the requirements of the conveying process, it can be transported by single or multiple belt conveyors or with other conveying equipment to form a horizontal or inclined conveying system to meet the needs of different layouts of production lines. ⌈ Diameter ⌋:500-1000 (mm) ⌈ capacity ⌋:25-980 (m³/h) ⌈ Application range ⌋:Sandstone yard, mining, metallurgy, mineral processing, coal mining and other industrial sectors. ⌈ Applicable material ⌋:River pebble, granite, basalt, iron ore, limestone, calcite, quartz, diabase, etc. |
Outstanding advantages |
Working principleThe belt conveyor consists mainly of two end rollers and a closed conveyor belt tightly fitted over it. The rotating drum of belt conveyor is called driving drum; Another roller used only to change the movement direction of the conveyor belt is called the reversing roller. The drive roller is driven by a motor through a speed reducer, and the conveyor belt is driven by the friction between the driving drum and the conveyor belt. The drive roller is generally installed at the discharge end to increase traction and is conducive to dragging. The material is fed from the feeding end, falls on the rotating conveyor belt, relying on the friction between the material and the conveyor belt to transport the material to the discharge end. |
Technical Parameters
| Model | Capacity(m³/h) | Diameter(mm) | Motor power(kw) |
| B500 | 25-143 | 500 | 3-5.5 |
| B650 | 40-243 | 630 | 4-7.5 |
| B800 | 75-500 | 630 | 5.5-15 |
| B1000 | 140-770 | 800 | 7.5-22 |
| B1200 | 200-980 | 1000 | 7.5-22 |
Our Services
One-Stop-Service for Your Project
7 x 24 h online service
1. Pre-sale services:
Act as a good adviser and assistant of clients
(1) Select equipment model;
(2) Design and manufacture products according to clients' special requirement;
(3) Train technical personnel for clients;
2.Services during the sale:
Respect clients; considering every aspect and details for our customers
(1) check products ahead of delivery;
(2)keep costumers informed about the delivery process
3. After-sale services
We promise excellent after-sale service!
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4)Take initiative to eliminate the troubles rapidly at site;
(5)Provide maintenance for big items.
And other rational requirement brought up by our clients.
Company Information
FAQ
Q: 1. To which country your products have been exported before?
A: Our products have been sold to America, Brazil, Chile, Sudan, Zambia, Kenya,Turkey, Indonesia,Malaysia, Philipines, Australia, India and so on.
Q: 2. How will you help the customer install the equipment?
A: Our senior engineer will guide the installation and commissioning as well as the initial production at
Q: 3. How about the wear parts supply?
A: We offer wear parts to our customer with our most favorable price. If there are problems youcould not handle, we will send our technicians to your place and you are therefore, responsible for all thecost involved.
My friend, feel free to contact me if you need any of our help. :)
